E-types of waves:
-Earthquakes generate
-Body waves (travel through the earth)
—> P and S waves
-Surface waves (travel along the surface)
—> Rayleigh and love waves
Body waves: Primary waves
-Primary waves, or P waves, travel through solid, liquid, and gas
-They are alternately compressional and expansive
-Their speeds are ~ 5km/s
-Rock vibrates parallel to the direction of wave propagation
Body waves: Shear waves
-Shear, or S waves, travel through solids
-They push material at right angles to their travel path
-Their speeds are 2-3km/s
-Rock vibrates perpendicular to the direction of wave propagation
Surface waves: Love
-Surface waves, such as love waves, are restricted to earth’s surface
-They cause sideways shaking of the ground
-Their speed is slightly less than S waves
-Love waves are the most dangerous waves
Surface waves: Rayleigh
-Rayleigh waves are similar to love waves
-But instead of causing shaking, they produce rolling morton of the ground
-Behave like ocean waves
A simple seismogram
-A seismogram is the graphical representation of earth movement
-The P wave is registered first, then the S wave, then the S-P interval, the difference between S
and S-P interval is the amplitude
F-sizes of earthquakes:
-The size of an earthquake is the main factor in its destructiveness
-We will look at two ways to estimate size:
—> Richter magnitudes
—> Mercalli index
-Mercalli intensity
-The modified mercalli intensity scale is used to assign a measure of destructiveness to
an earthquake (degree of damage caused)
-It is qualitative and based upon observed effects on people and damage to buildings
-Mercalli I: very weak, not felt by people
-Mercalli XII: total destruction
Richter magnitudes:
-The richter magnitude measures the maximum amplitude of ground shaking (vibrational
energy)
-It is a logarithmic scale
-1 richter unit difference is x 10 for ground motion and x 33 for energy
-Globally, small earthquakes are more frequent than large:
- ~ 800,000/yr for events of magnitude 2.0-3.4
-While an event of magnitude 8 occurs once every 5-10 years
G-estimating the epicentre of an earthquake
