Access 1.1
The quick access toolbar allows quick access tools such as save
Shutter Bar Open/Close Button: allows you to close and open the navigation pane
Navigation Pane: the area that lists all objects (tables, reports, etc.) in the
database and is the main for opening and working with database objects
Access assigns the default name “Table 1” to the first new table you create.
Datasheet View: shows the tables contents as a datasheet. The status bar indicates
the current view, in this case it is datasheet view
Access Window: the program window that appears when you create a new
database or open an existing database
The ribbon provides the main Access commands organized by task into tabs and
groups
Datasheet: displays the tables of contents in rows and columns
Field: is a single characteristic or attribute of a person, event, place, object or an
idea
Group related fields into tables. A Table: is a collection of fields that describes a
person, place, object, event, or idea.
Field Value: specific value or content of a field
Record: is a set of field values.
Relational Database/Database: a collection of related tables
Common Field: connecting the records in the separate tables
Primary Key: a field or a collection fields whose values uniquely identify each
record in a table
Foreign Key: when you include the primary keys from one table as a field in a
second table to form a relationship between two tables.
Database Management System (DBMS): is a software program that lets you create
data tables and then manipulate data in them
Relational Database Management System: data that is organized as a collection of

Only pages 1-3 are available for preview. Some parts have been intentionally blurred.

tables
Relational DBMS Provides The Following Functions:
-allows you to create database structures containing fields, tables, and table
relationships
-let you easily add new records, change field values in existing records, and delete
records
-it contains a built-in query language, which lets you obtain immediate answers to
the questions you ask about your data
-it contains a built in report generator, which lets you produce professional-looking,
formatted reports from your data
-it protects databases through security, control, and recovery facilities
Allows users in the same groups to share the same data
Template: a predesigned database that includes professionally designed tables,
reports, and other database objects that can make it quick and easy for you to create
a database
Data Type: determines what field values you can enter for the field
AutoNumber: automatically inserts a unique number in this field for every record,
there fore it can serve as the primary key for any table you create
Text Data Type: field values containing letters, digits, and other characters, and
which is appropriate for identifying numbers, such as contract numbers, that are
never used in calculations.
Row(Records) and Columns(Fields)
Field Sector/Record Sector: selects that entire column or row which you can
manipulate
Field Sector is also called a Column Selector, and a Record Selector is also called a
Row Selector
The pencil symbol indicates that the record is being edited
The star symbol identifies the second row as the next row available for a new
record
Quiz 1.1 Check
A field is a single characteristic of a person, place, object, event, or idea.
You connect the records in two separate tables though a common field

Only pages 1-3 are available for preview. Some parts have been intentionally blurred.

The primary key whose values uniquely identify each record in a table, is called a
foreign key when it is placed in a second table to form a relationship between the
two tables
The navigation pane is the area of the access window that lists all the objects in a
database, and it is the main control center for opening and working with database
objects
Which field does Access create by default, as the primary key field for a new table
in Datasheet view?
-ID Field
Which group on the fields tab contains the options you use to add new fields to a
table?
-Add & Delete
What does a pencil symbol at the beginning of a record represent? A star symbol?
-A pencil symbol representing that you are currently editing a record. A star
symbol indicates that the second row as the next row available for a new
record
Access 1.2
Form: a database, object you use to enter, edit, and view records in a database
Query Wizard: button opens a dialog box with different types of wizards that
guide you through the steps to create a query
Simple Query Wizard: allows you to select records and fields quickly to display in
the query results
You use the options in the Tables group to create a Table in Datasheet view or in
Design view
The Queries group contains options for creating a query: which is a question you
ask about the data stored in a database
Form Tool: quickly creates a form containing all the fields in the table(or query)
on which you’re basing the form
Form Wizard: guides you through the process of creating a form
The Report Tool: places all the fields form a selected table(or query) on a report,
making it the quickest way to create a report
Report Wizard: guides you through the process of creating a report
Report: a formatted printout of the contents of on or more tables in a database
