Respiratory Section #6
VI. ALVEOLAR VENTILATION-PERFUSION RELATIONS
A. Regional Lung Ventilation Differences
a. Can use radioactive xenon to detect how much ventilation is received by
various parts of lung. Bottom of lung gets more ventilation than top
b. Weight of lung causes greater pressures at lower lung. So intrapleural
pressure is more positive at bottom of lung.
c. Alveolar pressure equal in all parts of lung. Causes transpulmonary
pressure to be less at bottom of lung. Lower transpulmonary pressure
alveoli less expanded (inflated) in lower lung regions at rest
d. Not sure of these reasons for increased intrapleural pressure going down
lung. Absolute values constant across mammalian species varying 10^4 in
body size
e. Lower resting volume and lower transpulmonary pressure puts bottom
portions of lung lower and to the left. More compliance in this portion
for any inspirational pressure change, there will be greater volume change
in lower lung regions
B. Extreme Vrate Qrate Effects on Alveolar Gas Composition
a. Conc’n of a substance in a mixing chamber is dependent on 2 factors:
i. Rate of entry into chamber (gm/min)
ii. Rate of removal from chamber (L/min)
b. Entry of the substance into mixing chamber is analogous to ventilation in
lungs
c. Removal of substance from chamber is analogous to pulmonary BF
d. Thus, conc’n of substance in lungs is related to VArate/Qrate
(ventilation-perfusion relation: (gm/min)/(L/min) = gm/L)
e. Pressure of gas (O2) in lung is dependent on gas entry rate into gas
exchange area (VArate), and rate of gas entry out of lung (VO2rate)
1. No Ventilation
a. Gas within alveoli (and also blood leaving alveolar cap bed) will
have composition of mixed venous blood??
2. No Perfusion
a. No BF to alveolar space, then alveolar gas composition will be just
like humidified room air.
b. *Hyper ventilation always brings ur alveolar gas composition
values closer to that of inspired air (important during exercise and
at altitude)
3. Normal Alveolar Ventilation-Perfusion Relation
a. Resultant alveolar gas composition (POw = 100 and PCO2 = 40
mm Hg) is an average of all the lung
Unlock document

This preview shows page 1 of the document.
Unlock all 3 pages and 3 million more documents.

Already have an account? Log in

Document Summary

Alveolar ventilation-perfusion relations: regional lung ventilation differences, can use radioactive xenon to detect how much ventilation is received by various parts of lung. Bottom of lung gets more ventilation than top: weight of lung causes greater pressures at lower lung. So intrapleural pressure is more positive at bottom of lung: alveolar pressure equal in all parts of lung. Causes transpulmonary pressure to be less at bottom of lung. Lower transpulmonary pressure alveoli less expanded (inflated) in lower lung regions at rest: not sure of these reasons for increased intrapleural pressure going down lung. Absolute values constant across mammalian species varying 10^4 in body size: lower resting volume and lower transpulmonary pressure puts bottom portions of lung lower and to the left. If varate/qrate is normal, then logarithmic plot of end tidal fn2 versus breath number is linear: this is b/c at tidal volume ventilation, percentage decr of.
