CS 135 Winter 2013
Ashkan, Champaign
Assignment: 5
Due: Tuesday, February 26, 2013 at 9:00pm
Language level: Beginning Student
Allowed recursion: Pure structural
Files to submit: a05.rkt,a05bonus.rkt
Warmup exercises: HtDP 10.1.4, 10.1.5, 11.2.1, 11.2.2, 11.4.3, 11.5.1, 11.5.2, 11.5.3
Practise exercises: HtDP 10.1.6, 10.1.8, 10.2.4, 10.2.6, 10.2.9, 11.4.5, 11.4.7
The US Social Security administration publishes the 1,000 most popular male baby names and
the 1,000 most popular female baby names for each decade since 1890. See http://www.
socialsecurity.gov/OACT/babynames/ for more information.
You may search for specific names and see graphs of that name’s popularity through time at http:
//www.student.cs.uwaterloo.ca/˜cs135/assns/a05/nameSurfer/. Use it to
explore! For example, the name “Rock” has a spike right about the time Rock Hudson was a
popular movie star. Abdullah” appears very late in the American data. “Kelsey” shows a meteoric
rise in popularity in the 1980’s data. Adolf” (as in Hitler) was already a dead name by 1920.
One might find it surprising that “Adolph”, practically the same name, did not take a plunge in
popularity right after World War II.
The goal of this assignment is to produce the “guts” of a similar application.
Data on each name is recorded using the Nameinfo data type, defined as (define-struct nameinfo
(name decade rank gender)) where
name is a String
decade is a Natural number that is one of 1890, 1900, 1910, ... 2000. It indicates the decade
for which the information applies
rank is an Int in [1, 1000] indicating the popularity of name in the given decade where 1 is
the most popular name for the decade and 1,000 is the least popular name
gender is one of {Male, ’Female}and indicates the gender of the babies given the name.
The nameinfo structure has already been defined for you and used to create two lists. The first,
name-list, contains all 24,000 data points from the Social Security Administration data. The sec-
ond, short-name-list, contains only the names beginning with ”A” (2,057 data points). You may
find it useful for experimenting. To access these definitions in DrRacket, you need to do the fol-
lowing:
1. Download the file names.txt from the course website. Save it in the same directory where
your a05 Scheme programs will be saved.
CS 135 — Winter 2013 Assignment 5 1
You're Reading a Preview

Unlock to view full version

Only page 1 are available for preview. Some parts have been intentionally blurred.

2. Download the file namelist.rkt from the course website. Save it in the same directory
as names.txt.
3. In your Scheme program, include the line (require ”namelist.rkt”) at the beginning of your
program. For example, save the following in a05-demo.rkt. It should display the first
two names in the list.
(require ”namelist.rkt”)
(first name-list)
(first (rest name-list))
You will not submit namelist.rkt nor names.txt. We already have copies; you won’t be
changing yours.
All of the required functions will be submitted in a single file, a05.rkt, because they build on
each other for the last several problems. A syntax error in one will make all of them unmarkable.
For this reason you must use the public test to ensure your code can be tested. Do not change
your submitted code without reviewing the public test to verify that it (still) works correctly.
Here are the assignment questions you need to submit.
1. Write a full data definition and template for a Namelist, a list of Nameinfo structures.
2. Write the function find-rank. It consumes a Namelist, a name, one of {Male, ’Female},
and a decade. It produces the name’s popularity ranking for the given decade and gender.
Produce false if the ranking can’t be found.
3. Write the function collect-name. It consumes a Namelist, a name, and a gender. It produces
aNamelist composed of all the Nameinfos in the given list that match the given name and
gender. Order does not made.
4. Write the function first-n. It consumes a list and a natural number, n, and produces the first
nitems from the list. If there are fewer than nitems on the list evaluate (error ”Insufficient
items”). You should be able to do this without counting the number of items ahead of time.
5. Review the sort function on slide 06-29. It uses the insert function on slide 06-31. Adapt
these two functions to sort a Namelist in increasing order by name (you will find the predicate
String<?useful). If the names are the same, place females before males. If the name and
gender are the same, sort in increasing order by decade. Call the functions name-sort and
name-insert.Warning: if you try sorting the entire name-list you will be waiting for a long
time!
6. Write the function bar-graph. It consumes a list of natural numbers and returns a string such
that each number nin the list results in a sequence of n“*” characters. Each such ‘bar’
should be separated from the next by a newline character (“\n”). For example, (bar-graph
(cons 5(cons 10 (cons 3empty)))) should produce ”*****\n**********\n***\n”.
CS 135 — Winter 2013 Assignment 5 2
