**preview**shows pages 1-2. to view the full**8 pages of the document.**Alexander Magony

CSC108H1F 2014

Week 10

Analyzing Algorithms

-Up until now we’ve been concentrating on creating correct functions. Now we’re going to take a look at

the time it takes the the function to execute relative to the size of the input.

•Instead of timing it, we will look at the amount of steps it takes.

•Consider the following functions:

-print_ints executes the print

function n times, printing

every integer from 1 to n.

•As n increases, the

number of steps (in this

case, prints) increases

linearly (eg. 20 steps

when n is 40)

•Therefore, this function is

a linear function.

-print_odd_ints executes

the function roughly n/2

times, printing every odd

integer from 1 to n.

•This is also a linear

function, though the

slope is halved (eg. 20

steps when n is 40).

-print_pairs prints all possible pairs of integers from 1 to n.

•eg. n = 2 prints 4 times (1, 1), (1, 2), (2, 1), (2, 2). n = 3 prints 9

times. n = 4 prints 16 times. Basically, it prints n^2 times.

•This function is an exponential function (or quadratic).

•The inner loop executes n times (from the range 1 up to but not

including n + 1) and the outer loop also executes n times.

Therefore, the effect is multiplied together (the whole code

executes n*n times or n^2 times).

•If we had two functions that solved the same problem and one had a

linear runtime and the other a quadratic, we would choose the linear

as it is more efﬁcient.

-print_double_step prints integers from 1 to n, taking a step size that starts

off at 1 and doubles every subsequent step. So ﬁrst it steps 1 to

2 (step = 1), then 2 to 4 (step = 2), then 4 to 8 (step = 4), etc.

•This means n from 4-7 all have 3 steps/prints, n from 8-15

have 4 steps/prints, 16-31 have 5 steps, etc.

•This function is a logarithmic function, proportional to log

base-2 of n.

•As n grows, the number of steps grows more slowly.

1

Only pages 1-2 are available for preview. Some parts have been intentionally blurred.

Alexander Magony

CSC108H1F 2014

Linear Search

-linear search: search items one by one in a list.

•If we use the help(list.index) we see that it ﬁnds the ﬁrst occurrence of an item. So if ‘a’ appears at

index 0 and 4, it will still return 0, since that is the ﬁrst occurrence.

-This is because this method searches the list linearly, starting at index 0, moving to 1, then 2, and

so on towards the end of the list until the ﬁrst

occurrence is found.

-Visualizing the search (ignore the background

blue text): we draw the values that each index

refers to in a line. We start off with i referring to

index 0.

-If we are searching for v, which refers to ‘d’, we

check i. It isn’t the index which refers to ‘d’ so

we add 1 and check the next index. We repeat

this until we reach index 4 which does refer to

‘d’.

-If we make v refer to something that doesn’t

belong in the list, we return -1 (not sure why).

-We are going to explore linear search by writing a function that implements it.

-This function takes a list and a character to search for and returns the ﬁrst index it is found at. If it isn’t

found at, we return -1. Obviously, based off of the

list.index method.

•He goes on to draw some visualizations of the

possible cases (general case where v is in the list

and the case where v isn’t in it) but it seems pretty

simple.

•If v isn’t found in the list L, i (starting at 0) will be

added to until i = len(L). Therefore, we will create a

while loop while i != len(L): to deal with this.

•We also need to account for if v is found in i. So we

will add the condition and v != L[ i ] to the while loop

condition. In this while loop, we will accumulate 1 to

i.

•if i == len(L):, we can return -1.

•The only other case is that i is not equal to the

length of L but v is found to equal L at some index.

So we can write else: and return the i that it is

found at.

•He really goes through and continues to visually demonstrate why we coded it the way we did. I

think it’s super easy and logical but if you disagree go watch the third video: https://

teach.cdf.toronto.edu/StG108/content/challenges/30/1

Binary Search

-Linear search works both on unsorted and sorted lists by working through each index one by one,

linearly. If the list is sorted, we can do much better with a binary search.

-In our example, we create a function that searches for the ﬁrst index occurrence of v, returning the

index and -1 if it is not found.

•Let’s say we have a super long list (100,000 items). Searching this list linearly would take

relatively long.

2

###### You're Reading a Preview

Unlock to view full version

Only pages 1-2 are available for preview. Some parts have been intentionally blurred.

Alexander Magony

CSC108H1F 2014

•Alternative: we examine the middle index of the list and compare it to v. If the index is less than v,

and since the list is sorted, we can exclude the whole ﬁrst half of the list from our search since it is

all less than the index which is less than v. With the example of the 100,000 long list, we reach

the same point in one comparison that linear search would have in 50,000 comparisons.

•We use b and e to describe the two indices which include the range of indexes which we know

nothing about (eg. any of these could be v). b is initially 0 and e is initially

len(L) - 1 (ie. the last index).

-As we analyze the list and start excluding portions of the list, the

unknown range decreases (b increases and e decreases).

-When we ﬁnd the item, the unknown range is empty. e is to the left of the found value and b is

to the right.

•So to go over this in terms of our mathematical approach: after we initially set b and e, we choose

the midpoint m between b and e and compare it to v.

-If L[m] < v, b can be moved up to m + 1, since we can

now assume m and everything before it is below our

target value.

-If L[m] >= v, e can be moved down to m - 1, since m and

everything above it is greater than or equal to v.

-We will continue until e is less than b, indicating there is

no more unknown areas of the list. Therefore we will

build the following while loop.

•We must now account for if v does not exist in the list

and we must return -1. The whole list is either greater

than/equal to or less than v.

-If the whole list is less than v, b is moved up all the

way until it is the last index + 1 (ie. len(L)). So we

will write if b == len(L) or L[b] != v:. Since this occurs

after the while loop ﬁnishes moving b and e, if the

value at index b is not v at this point (or if it the index

is len(L) which does not exist in the list), we must

return -1.

•If b is not len(L) AND does refer to an index with a

value that equals v, we want to return index b. We can

include this in the else statement to the previous if-or

statement.

-Once again, he visualizes the process, so watch the video if

you’re left confused: https://teach.cdf.toronto.edu/StG108/content/challenges/31/1

-In short, binary searches use the fact that the list is sorted to search and exclude portions of the list

more systematically than linear functions.

Comparing Search Algorithms

-Let’s compare both searches by comparing the amount of comparisons and statements that occur

(gives us a VERY rough estimate as to which is quicker).

3

Final function:
