EESA10 Lecture 6
Radiation and Human Health
Slide 1 – Radiation and Human Health
•Radiation is everywhere, all around us. We cannot escape radiation. But the
question is what type and how much radiation is there.
•Even if we are walking outside in the woods, we are still exposed to some
radiation, because of Background Radiation: Something that is produced and emitted
from outer space. Natural radioactivity in the earth and by cosmic rays from outer
space. This type of radiation cannot be controlled. We are always exposed to it. It has
existed for hundreds of thousands of years.
•Something that we can control is man made radiation (Electronic devices,
appliances, etc.). (Note: Nowadays, engineers have found technologies to protect us
from most of this radiation). Examples of some man-made devices that emit different
types of radiation include:
- X-ray machines (different kind of equipment used in labs for analysis, for example,
CCA can also be detected using X-ray)
- X-ray Diagnostic (X-ray used for diagnostic of different body parts)
- Television sets
- Microwave ovens
Slide 2 – Ionizing radiation exposure to the public
•Natural radiation sources consists of 82% of total measurable radiation
•Man-made radiation is just 18%. Medical x-rays, nuclear medicine can treat
some illnesses and some other types of radiation. What is surprising is that Radon
(gas in indoor air) makes up 55% of total radiation.
Slide 3 – Radiation and Human Health
•We have two big groups of radiation:
1) Ionized Radiation (Cosmic, Gamma, X-rays): This is radiation that has so much
energy that can change atoms on some other chemicals. They can push electrons out
of their atoms and produce ionized form of that element. They are very strong as they
have so much energy. (Note: On electric spectrum, elements that are very high in
energy have short wavelength, elements with low energy (non-ionized) have long
2) Non-Ionized Radiation (Radio waves, TV waves, Microwaves): This type does not
have enough energy (low in energy) and they cannot remove electrons from atoms.
Slide 4 – Ionized Radiation
Only pages 1-2 are available for preview. Some parts have been intentionally blurred.
•Affect of this radiation is obvious. All scientists agree that this radiation is
really harmful. How does it affect human health? First, the radioactive material (like
Uranium), decays naturally and spontaneously, and produces ionizing radiation. This
ion radiation, strips away electrons from atoms (create two charged ions)
•It can also break some chemical bonds. This is important for human body as
it consists of water and chemicals. Examples: alpha, beta particles, gamma and x-
rays. These examples differ based on the amounts of energy they have.
Slide 5 - Health effects from exposure to radionuclides
There are 2 different kinds of health effects.
1) Stochastic effect – Humans exposed to long term, lower level of radiation. This is most
problematic because it is very hard to detect and to know what will happen to our health
after long time exposure to lower level of radiation. Hard to detect and not 100% known.
What is known is that if the amount of radiation increases the severity of this affect will not
change and will stay the same and the type of illnesses will be the same. But the risk to get
that illness will increase. Risk of getting cancer will be higher. This amount of radiation is
proven to cause cancer. 2 effects associated with this Stochastic:
Cancer is uncontrolled growth of cells (any kinds of cells as there are many kinds of
cancers). Naturally in our physiological functions, our cells divide and produce new ones to
replace old ones. This natural physiological process is controlled by our genetic material.
But if certain radiation disrupts this natural process, it will cause cancer. Basically, cells
keep on growing without reason. And this reason is radio nuclides.
Another effect that can be caused is changes in DNA (changes to genetic material). Two
problems can happen because of this. One is Teratogenic changes and another is genetic
changes (mutations). What are teratogenic effects: birth defects. Mother is exposed for long
term to lower level of radiation (most sensitive in 8- 15 week of pregnancy) ; her unborn
child will have some problems like smaller head or brain size, poorly formed eyes, mental
retardation. Genetic mutations are changes that can be transferred from the parent to the
child. Teratogenic changes cannot be transferred to the child, but the offspring is affected
anyways, which we see when child is born.
2) Non-Stochastic effect – These are acute effects. These effects are seen in humans that
are exposed to very high levels of radiation for a short period of time. These effects are also
very visible and obvious. These effects, if level of radiation increases, will get more severe.
We know this based on cases of many different nuclear accidents everywhere (Chernobyl,
Hiroshima Nagasaki, workers that are exposed to very high level of radiation etc.).
Some literature says that these effects can cause cancer, but some literature disagrees
that it causes cancer. Based on Epidemiological studies and other examples, it seems that
yes these effects can cause cancer, because most data shows increased number of different
types of cancer in areas such as Chernobyl or where we saw some accidents.
What we know for sure is that this high level of radiation causes radiation sickness
(nausea, weakness, hair loss, skin burn or diminishing organ function, premature aging,
death). Death comes usually after two to three months.
Nuclear power plant accidents
1) Three Mile Island, Pennsylvania, 1979: Researchers did not find much adverse effects
after this accident. Because the radiation level was so low that it was not high enough to
cause long term health effects.
