Week 9 review
o Q1 What singals would the control unit turn on and off inorder to
add $r1 to $r2 and store the result in $r7?
PCWrite = 0, PCWriteCond = X
IorD = X
MemRead = 0, MemWrite = 0
MemtoReg = X
IRWrite = 0
PCSource = x
ALUOp = 001 (add)
ALUSrcA = 1, ALUSrcB = 0
RegWrite = 1, RegDst = 1 (R-type)
o Q2 What signals would the control unit turn on and off in order to
add 100 to the program counter?
100
PCWrite = 1, PCWriteCond = X
IorD = X
MemRead = 0, MemWrite = 0
MemtoReg = X
IRWrite = 0
PCSource = 0 or 1
ALUOp = 001 (add)
ALUSrcA = 0, ALUSrcB = 2
RegWrite = 0, RegDst = X
o Q3 same as week 10 review Q1
o Q4 same as week 10 review Q2
o Q5 same as week 10 review Q3
