55-101 Lecture Notes - Suprachiasmatic Nucleus, Signal Transduction, Retina Horizontal Cell

42 views2 pages
Outline of Lecture 61 and 62 (03-25 C and 03-25 D; Yau)
Photoreceptors and Retina
0. Introduction
- Images from the retina are analyzed for form/movement/color, then later for depth
- Development of retina: omitted from this outline, not covered in lecture
I. Structure of retina
- The retina is composed of three main layers
1) Outer nuclear layer: photoreceptors, no direct blood supply
2) Inner nuclear layer: bipolar, horizontal, amacrine, Mueller glial cell bodies
3) Ganglion cell layer: retinal ganglion cells
- The outer and inner plexiform layers are sites of synapses between layers
II. Photoreceptors
- There are two types of photoreceptors
1) rods: most sensitive in dim light, only one type
2) cones: less sensitive to light, three types mediate color vision
- Distribution of photoreceptors is not uniform: fovea has high density of cones and few rods,
periphery has more rods
- The outer segment of rods and cones have stacks of disks with high density of pigment and
provide a high probability of absorption of an incident photon
- Pigment epithelial cells serve to (1) absorb light not absorbed by the rods/cones using melanin,
(2) phagocytose shedded fragments of rods/cones, (3) regenerate pigment
III. Visual pigments
- Pigment is composed of a chromophore covalently bound to an opsin 7TM protein
- Humans have 4 pigments (1 rod, 3 cones) each maximally sensitive at different wavelengths
- Upon photon absorption, the chromophore undergoes several configuration changes; the
configuration that triggers vision takes several ms to reach; the ultimate result is the release of
chromophore, and binding of fresh chromophore with opsin
IV. Phototransduction
- Rods/cones hyperpolarize in response to light in a graded fashion with respect to intensity, with
cones requiring more light and responding more rapidly
- Phototransduction mechanism is shown on p. 10, a prototypical signal transduction mechanism
- In dark, cGMP keeps a nonselective cation channel open, and cell is depolarized
- Rhodopsin is coupled to G-protein that activates phosphodiesterase and lowers [cGMP]
- Ca influx plays a key negative feedback function and mediates light adaptation
V. Synaptic connections in the retina (see Figure on p. 12)
- Throughput pathway: photoreceptor bipolar retinal ganglion cell optic nerve
- Lateral associations: between photoreceptors, and via horizontal and amacrine cells
- There are distinct synapse morphologies in the retina
- Synaptic triad: photoreceptor with horiztonal-bipolar-horizontal cells, and contains a synaptic
ribbon
- Dyad: proximal bipolar end synapses with two cells
- Primary nxt’s in the retina are Glu (excitatory) and GABA (inhibitory)
VI. Information processing in the retina
- The receptive field of a single photoreceptor is bigger than itself due to connections with
neighboring photoreceptors; for the same reason, the receptive field of horizontal cells is bigger
than the multiple photoreceptors it contacts
Unlock document

This preview shows half of the first page of the document.
