Lecture 11 3/25/2013 9:10:00 AM
Our Window on the Universe:
Near Earth Asteroids:
Rocky objects orbiting the sun at a distance similar to earths orbit.
Objects do not stay in such orbits for very long‖ within a few million
years they are likely to be kicked into another orbit by gravitational
Most came from the asteroid belt (between mars’s and jupiter’s
orbits) fairly recently.
A small rocky object (generally less than 10m across) in the solar
The visible phenomenon of a meteoroid or small asteroid entering
the earth’s atmosphere, glowing as it heats up.
A rock (formerly a meteoroid or fragment of an asteroid) that has
fallen to the ground from outer space. (most objects smaller than
10m vaporize completely in the atmosphere.
Tides: Another Consequence of Gravity:
Newton’s Law of Universal Gravitation:
o Any two object attract each other with a force proportional to
the product of their masses and inversely proportional to the
square of the distance between their centres.
F = G M1M2/r^2
o That means that, for example, the moon exerts a greater
force on a piece of earth close to the moon than on the
centre, or the opposite side.
Tides are mostly noticeable in the oceans, but the earth’s crust
itself also bulges slightly (about 10-50cm) in response to tidal
Over time, tidal bulges can affect an objects rotation.
The synchronous rotation of the moon (same side always faces the
earth) is probably a result of ―tidal locking.‖
Light: Our Messenger From the Universe:
What is light:
o The warmth of sunlight reminds us that light is a form of
o Energy can take many forms and can be converted from one
form to another
o Some other forms of energy: kinetic energy (energy of
motion), heat, sound, chemical energy, etc…
o When light from th sun warms the ground or your skin, light
energy is being converted into heat. Solar power plants
convert light into electrical energy. Green plants convert light
into chemical energy through photosynthesis.
Light is a form of energy:
o Units of energy: joules
o 1 Joule of energy is enough to:
start a 2-kg object moving at 1m/s
heat of 1 gram of water by approx. 0.25 degrees C
o Watts are a unit of power: energy per unit time.
1 watt = 1 joule/sec. so:
a 100W light bulb is using 100 joules per second
(only part of that energy is actually emitted as
light—the rest of it mostly becomes heat)
Quantifying Light Intensity:
intensity of light can be measured in W/M^2
what does this mean?
Well, if the intensity of light from a source is measured to be
1/W/m^2, then that means the amount of energy falling every
second on every square meter of surface is 1 joule (if that surface
is perpendicular to the direction the light is coming from)
The intensity of light is related to its brightness.
To summarize: light involved a flow of energy. intensity tells
you how much energy is passing through each unit of
perpendicular area each second.
But if a surface Is at an angle, then the same energy is spread over
a larger area.
Inverse Square Law (for light intensity):
As you get farther from the source, the same energy gets spread
over a larger area.
That means that the intensity decreases at you get farther away
from the source.
Stars that are farther away look dimmer than they would up close.
Mathematically speaking, light acts like gravity: if you double the
distance, the intensity becomes ¼ as much—triple the distance,
intensity becomes 1/9 as much, etc.
This is because if you double the distance, the same amount of light
energy gets spread over four times as much area.
That’s the same type of mathematical behaviour as in Newton’s law
of gravity (gravity gets weaker as distance increases but never
really goes away.)
Light: wave or Particle?
1670, Hooke, Huygens: light behaves like a wave.
1700, Newton: light consists of particle (corpuscles)
1800, Young, Fresnel: showed wavelike properties of light
1873, Maxwell: identified light as electromagnetic waves
1905, Einstein: light consists particles of energy called ―photons‖
so is light made of particles or waves?
1920’s-30’s: quantum Mechanics: light behaves as both, particles
and wave. Which properties are apparent depends on how you
Is light a wave or a particle?
The real answer‖ ―its complicated‖
Leaving out some details, we can say that light travels through
space as a wave, but some of its interactions with matter
(absorption, emission) are best understood in terms of particles.
What are waves?
A wave is a periodic (repeated) motion that can carry energy
without carrying matter along with it.
