**preview**shows pages 1-3. to view the full**16 pages of the document.**Instructor Notes - Chapter 16 - page 233

Chapter 16: Introduction to Regression

Chapter Outline

16.1 Introduction to Linear Equations and Regression

Linear Equations

Regression

The Least-Squared Error Solution

Using the Regression Equation for Prediction

Standardized Form of the Regression Equation

The Standard Error of Estimate

Relationship Between the Standard Error and the Correlation

16.2 Analysis of Regression : Testing the Significance of the Regression Equation

Significance of Regression and Significance of the Correlation

16.3 Introduction to Multiple Regression with Two Predictor Variables

Regression Equations with Two Predictors

R2 and Residual Variance

Computing R2 and 1 â€“ R2 from the Residuals

The Standard Error of Estimate

Testing the Significance of the Multiple-Regression Equation: Analysis of Regression

16.4 Evaluating the Contribution of Each Predictor Variable

Multiple Regression and Partial Correlations

Learning Objectives and Chapter Summary

1. Students should understand the concept of a linear equation including the slope and

Y-intercept.

All linear equations have the form Y = bX + a where a and b are constants. The value of

b is the slope of the line and measures how much Y changes when X is increased by one

point. The value of a is the Y-intercept and identified the point where the line crosses the

Y axis.

find more resources at oneclass.com

find more resources at oneclass.com

Only pages 1-3 are available for preview. Some parts have been intentionally blurred.

Instructor Notes - Chapter 16 - page 234

2. Students should understand the concept of a least-squared-error solution.

The regression equation is obtained by first finding the distance (or error) between the Y

values in the data and the Y values predicted by the regression equation. Each error is

then squared to make the values consistently positive. The goal of regression is to find

the equation that produces the smallest total amount of squared error. Thus, the

regression equation produces the â€śbest fittingâ€ť line for the data points.

3. Students should understand and be able to compute the linear regression equation for

predicting Y values from the X values in a set of correlational data

The regression equation is determined by the slope constant, b = SP/SSX and the Y-

intercept, a = MY â€“ bMX, producing a linear equation of the form Y = bX + a. The

equation can be used to compute a predicted Y for each X value in the data.

4. Students should understand the concept of multiple regression. Increasing the number of

predictor variables usually produces more accurate predictions. Although the task of computing

a multiple-regression equation is tedious, students should be able to follow the formulas and

produce a two-predictor formula for a relatively simple set of data

The simple concept is that each variable provides more information and allows for

more accurate predictions. Having two predictors in the equation will produce more

accurate predictions (less error and smaller residuals) than can be obtained using either

predictor by itself

5. Students should understand the concept and process of evaluating the significance of a

regression equation by comparing the predicted variance with the unpredicted (residual) variance

The total variability of the Y scores is measured by SSY with df = n â€“ 1. Part of this

variability is predicted by the regression equation and part is not. For linear regression,

the predicted portion is determined by r2 and has df = 1. The unpredicted portion is the

remaining or residual part and is determined by 1 â€“ r2 and has df = n â€“ 2. For multiple

regression, the predicted portion is determined by R2 and has df = 2. The unpredicted

portion is determined by 1 â€“ R2 and has df = n â€“ 3. In each case, SS/df can be used to

compute a variance for the predicted portion and a corresponding variance or MSresidual

for the unpredicted portion. Finally, the significance of the equation is determined by an

F-ratio

MSregression

F = â”€â”€â”€â”€â”€

MSresidual

find more resources at oneclass.com

find more resources at oneclass.com

Only pages 1-3 are available for preview. Some parts have been intentionally blurred.

Instructor Notes - Chapter 16 - page 235

Other Lecture Suggestions

1. With linear regression, the calculations are simple enough to allow computation of the actual

regression equation, especially if you use a simple set of scores such as the data in problems 7

and 10 at the end of the chapter. However, it is probably best to focus on the concepts of

predicted versus unpredicted (residual) variance, and using the regression equation to find a

predicted Y value for each X.

a. For each X, you can compute the predicted Y, then find the residual (Y â€“ Ĺ¶) and

squared residual. The sum of the squared residuals is equal to (1 â€“ r2)SSY.

b. An alternative is to convert the original Y values into deviations before finding the

regression equation. Plugging X values into the resulting equation will now produce

predicted deviation scores. If the predicted deviations are squared, the sum of the

squared values will be equal to r2SSY. = SSregression.

2. For multiple-regression is probably is best to start with the regression equation or use a

computer in class to generate the regression equation. Then, focus on the concepts of predicted

versus unpredicted variance and use the equation to find the predicted Y value for each pair of

predictors.

3. The following values provide another example of relatively easy numbers for a linear

regression equation.

X Y

3 3 For these data, SP = 10, SSX = 10, and SSY = 40, producing

4 9 a correlation of r = 0.50 and a regression equation of

0 5 Ĺ¶ = X + 2

2 2

1 1

4. The concepts of partial correlation and multiple regression are probably easier for students to

understand if a third variable is added to an existing X-Y correlation. The third variable is the

second predictor for multiple regression and is the variable to be controlled by the partial

correlation. In this context, the role of the third variable is easier for students to understand if it

is presented as a variable that separates the sample into distinct groups. For example, within a

specific age group, there probably is no consistent relationship between a studentâ€™s weight (X)

and his/her performance on a mathematics skill test (Y). Thus, the underlying correlation

between X and Y is r = 0. However, if age is added as a third variable so we now have three

groups consisting of 6-year-old, 8-year-old, and 10-year-old children, the combined sample will

show a clear, positive correlation between weight and math performance. The correlation is due

to the fact that weight and math skill both increase as age goes up. The partial correlation

find more resources at oneclass.com

find more resources at oneclass.com
