ANAT CH 11
Muscle Attachment
- Skeletal muscles make movement by exerting force on the tendons which then are attached to and
pull on bones to make movement
- When a muscle contracts, one articulate bone is drawn to the other
o One bone is stationary due to other muscles stabilizing the bone by contracting or pulling
the other way or because it has a less movable structure while the other bone moves
- Reverse muscle action (RMA): actions are reversed in the body; origin and insertion switch
Origin and Insertion
- Origin: the attachment of a muscles tendon to the stationary bone
o proximal
- Insertion: the attachment of the muscles other tendon to the movable bone
o Distal
o Pulled toward the origin
- Belly: fleshy portion of muscle between the tendons
o Ex: triceps
Lever System
- Bones are levers and joints are fulcrums
- Lever: rigid structure that can move around a fixed point (fulcrum)
o Lever is acted on by the effort (causes movement) and the load/ resistance (opposes
movement)
- Effort: force exerted by contraction
- Load: weight of body part being moved or the resistance the body part is trying to overcome
- Motion = E > Load
- Ex: bicep curl
o Elbow Is the fulcrum
o Weight of forearm + dumbbell is the load
o Force of contraction of the bicep brachii pulling the forearm up is the effort
Mechanical Advantage and Disadvantage
- Determined by the distance between the fulcrum and load and the point at which the effort is
applied
- Mechanical advantage: load is closer to fulcrum
o Small effort is required to move a large load over a small distance
- Mechanical disadvantage: load further from fulcrum and effort applied closer to fulcrum
o Large effort needed to move a small load at greater speed
Types of Levers
1) First Class
a. Fulcrum between the effort and load
b. Can make mechanical advantage or disadvantage depending on whether E or L is closer
to F
c. seesaw
2) Second class
a. Load is between the fulcrum and effort
b. Mechanical advantage
i. Load closer to fulcrum
ii. Favors force
find more resources at oneclass.com
find more resources at oneclass.com
c. Makes most force
d. Ex: calf raise
3) Third class
a. Effort between fulcrum and load
b. Mechanical disadvantage
i. Favors speed and range of motion
c. Ex: bicep curls
Fascicle Arrangement
- Muscle fibers are parallel and arranged in bundles called fascicles
- Fascicles are in different patterns w/ respect to the tendon:
o Parallel
Greater range of motion and less power
Parallel to longitudinal axis of muscle
Terminate at either end in flat tendons
Ex: sternohyloid muscle of the neck
o Fusiform (narrow ends and wide middle)
Nearly parallel
Terminate in flat tendons
Ex: digastric muscle
o Circular
Concentric circular arrangement
Form sphincter muscles
o Triangular
Spread over broad area at thick central tendon
Ex: pec major
o Pennate (feather)
Short fascicles
More power and smaller range
Unipennate:
Fascicles arranged on one side of the tendon
Bipennate:
Fascicles arranged on both sides of centrally positioned tendons
Multipennate:
Fascicles attach obliquely from many directions to several tendons
- Fascicle arrangement affects the muscles power and range of motion
o Longer fiber = greater range of motion
o More fibers per unit of cross sectional area = more power
Coordination among Muscles
- Several skeletal muscles act as a group to make movement
- Most muscles are arranged in opposing pairs at the joints
- Agonist/ prime mover: contracts to cause an action/ generates movement
- Antagonist: yields to the effect of the agonist
- Synergists: contract and stabilize intermediate joints
o Prevents unwanted movement at intermediate joints or aids movement of the prime
mover
- Fixators: stabilize the origin of the prime mover so it can act more efficiently by steadying the
proximal end while movement occurs
- Compartment: group of skeletal muscles, blood vessels and nerves
find more resources at oneclass.com
find more resources at oneclass.com
