File Systems (cont.)
Goals:
1. Archival storage - keep FOREVER, including prev. Versions
2. Support various storage technologies (i.e. different types of disks)
How to best achieve & balance
- Performance
- Reliability
- Security
Note: increasing one may decrease another!
Storage Abstraction
-hide complexity of device
-model as array of blocks of data (numbered, fixed size)
-randomly addressable by block #
-generally a multiple of disk size
-simple interface
-read(block #, mem_addr)
-write(block #, mem_addr)
Typical Implementation Structure
-”superimpose” a structure in the array of blocks
-3 regions:
1. File System Metadata - data about the ENTIRE file system
2. File Metadata - data about a particular file
3. Data Blocks - file contents
File System Metadata
-starts at 0
-if we know how to access FSM, we know how to access the other parts!
-which we know b/c it starts at 0!
-sizes
-files in use, files free
-how many blocks in EACH region, and how many are FREE
-free lists (or bitmaps)
-file control blocks
-data blocks
File Metadata
-occupies a certain # of “storage” blocks in our abstract storage device
-file control block: small amount of metadata for a file
-EACH block has a FCB
-typically, many FCBs fit into 1 storage block
-in each FCB:
Unlock document

This preview shows pages 1-2 of the document.
Unlock all 5 pages and 3 million more documents.

Already have an account? Log in
- attributes - type of file, size, permissions
- references to data blocks (i.e. disk block “map”)
Example of FCB
-Name is a number (i.e. index) -to the OS, not the User
Ex:
Number: 88
Size: 4096 bytes
Permissions: rw-r--r--
Data blocks: set of indexes into storage array
-what about file name?
Keeping Track of Allocated Blocks
1. Contiguous blocks - pointer & number
Pointer: first data block
Number: how many contiguous blocks for the file?
-SINGLE sequence
2. Non-contiguous blocks - pointer per block
Can get astronomically big if we have MANY blocks for a file!
Advantage: we can allocate blocks anywhere!
Disadv: have to record each location
3. Extents - array of “extents” - pointer & number
Ex: 2 contiguous regions of blocks: 2 & 3
-may need a lot of space if we have many contiguous blocks all over the place!
Example: UNIX v.7 Block Map
13 pointers:
- 10 are direct pointers (point to data block w/ data)
- This data block does not have file content, but actual pointers to data blocks WITH data
If block size was 1 KB, and we had 4-byte pointers, we could have 256 addressable DBs
Special Indirect Pointers: point to a data block that has pointers in them!
- 1 singly-indirect: references n data blocks
If block size was 1 KB, and we had 4-byte pointers, we could have 256 addressable DBs
Special Indirect Pointers: point to a data block that has pointers in them!
- 1 doubly-indirect: references n2 DBs
256 pointers to singly-indirect blocks → 256 x 256 x 1KB = 64MB
- 1 triply-indirect: references n3 DBs
256 x 256 x 256 x 1KB = 16GB
Can now reference a file that is UP to 16GB with JUST 13 pointers!
Reasoning: there are MANY small files, and VERY FEW large files
Keeping Track of Free Blocks
