SFWR ENG 3BB4 Summary
Dr. Maibaum
Winter 2015
McMaster University
Primary Author: Kemal Ahmed
This course is about concurrency in systems.
SFWR ENG 3BB4 Summary
e.g.
Action hiding
LTSA
Synchronized
Java
Monitors
Interference
Bounded Buffer
Deadlock
Safety & Liveness property
Progress Properties
Dynamic Systems
Linda
Templates
Tuple Space Model
Timed Systems
Concurrent Sof tware:
Distributed Software:
We represent models of concurrency using finite state machines (a.k.a. FSP).
Threads
active entities because they initiate actions
Opposite of monitors
Sequential process:
Processes: units of sequential execution
Models of Processes:
Finite State Processes (FSP): model processes as sequence of actions in an
algebraic f orm
Labelled Transition Systems (LT S): analyzes, displays, animates behaviour in a
graphical f orm
Labelled Transition Systems Animator (LTSA): a cool program
FSPs follow algebraic rules, such as:
Associativity: order of which operations to perform is sometimes irrelevant
Communitivity: x || y = y || x
Associativity: x || (y || z) = (x || y) || z = (x || z) ||y
State Machine Details:
Colour coding is sometimes used
Blue generally defines arbitrary states
Red generally defines the first state
An arrow without a head is still the standard for the beginning state, like from 2FA3
Arrow is triggered by a condition and
Trace: a possible sequence of actions; there can be multiple traces for a given FSM
Maximal trace:
Action [x]:
Process [P]: processes are ALWAYS CAPITALIZED
(x -> P) : a representation of a process, engaged by an action, x, and does the process, P
e.g.
SWITCH = OFF
OFF = (on -> ON),
ON = (off -> OFF).
SWITCH = OFF,
OFF = (on -> (off -> OFF)).
SWITCH = (on -> off -> SWITCH).
One rule of precedence that allows you to remove brackets is that you execute from Right
to Left
(x -> P | y -> Q) : engages in either the first or second action, depending on the input
that selects it
Concurrency:
Parallelism:
Are there shared actions?
Labels: ( label:Process | e.g. a:P )
Prefix Labels: useful f or modelling shared resources ( {set of prefix
labels}::Process | e.g. {a1,..,ax}::P )
When youre implementing a parallel database, you need to make sure that you dont do half
the re-saving/editing processes before you allow someone else to open the file.
Equivalent: same trace
Action hiding
P = (C -juice-> J,
J -return-> P ) {return}
this hides the return function
Shared Objects
How do you allocate access to a resource among multiple processes?
Mutual Exclusion: when only one process can access a resource at a time
Semaphor
Something that enables access to a resource
