Document Summary

According to newton"s second law, a net force causes an object to have an acceleration. The amount of torque depends on where and in what direction the force is applied, as well as the location of the axis of rotation. Magnitude of torque = (magnitude of the force) x (lever arm) Torque ( ) is defined as the force applied multiplied by the moment arm (or lever arm). Direction: the torque is positive when the force tends to produce a counterclockwise rotation about the axis, and negative when the force tends to produce a clockwise rotation. The acrobat controls the net torque acting on her center of gravity by manipulating the pole. Also, the acrobat holds the pole low, moving her center of gravity closer to the rope. A counterclockwise torque is designated as positive (+) A clockwise torque is designated as negative ( ) Why internal forces do not contribute to net torque.

Related Questions

A force F⃗ of magnitude F making an angle θ with the x-axis is applied to a particle located along the axis of rotation A, at Cartesian coordinates (0,0) in the figure. The vector F⃗ lies in the XY plane, and the four axes of rotation A, B, C, and D all lie perpendicular to the XY plane. (Figure 1)

A particle is located at a vector position r⃗ with respect to an axis of rotation (thus r⃗ points from the axis to the point at which the particle is located). The magnitude of the torque τ about this axis due to a force F⃗ acting on the particle is given by

τ=rFsin(α)=(moment arm)⋅F=rF⊥,

where α is the angle between r⃗ and F⃗ , r is the magnitude of r⃗ , F is the magnitude of F⃗ , the component of r⃗ that is perpendicular to F⃗ is the moment arm, and F⊥ is the component of the force that is perpendicular to r⃗ .

Sign convention: You will need to determine the sign by analyzing the direction of the rotation that the torque would tend to produce. Recall that negative torque about an axis corresponds to clockwise rotation.

In this problem, you must express the angle α in the above equation in terms of θ, ϕ, and/or π when entering your answers. Keep in mind that π=180degrees and (π/2)=90 degrees.

Part A

What is the torque τA about axis A due to the force F⃗ ?

Express the torque about axis A at Cartesian coordinates (0,0).

τA =

SubmitHintsMy AnswersGive UpReview Part

Part B

What is the torque τB about axis B due to the force F⃗ ? (B is the point at Cartesian coordinates (0,b), located a distance b from the origin along the y axis.)

Express the torque about axis B in terms of F, θ, ϕ, π, and/or other given coordinate data.

τB =

SubmitHintsMy AnswersGive UpReview Part

Part C

What is the torque τC about axis C due to F⃗ ? (C is the point at Cartesian coordinates (c,0), a distance c along the x axis.)

Express the torque about axis C in terms of F, θ, ϕ, π, and/or other given coordinate data.

τC =

SubmitHintsMy AnswersGive UpReview Part

Part D

What is the torque τD about axis D due to F⃗ ? (D is the point located at a distance d from the origin and making an angle ϕ with the x axis.)

Express the torque about axis D in terms of F, θ, ϕ, π, and/or other given coordinate data.

apricotclam488

1. If an object is rotating clockwise, this corresponds to a _____ angular velocity:

a- negative

b- positive

2. The angular displacement of a rotating object is measured in

a- degrees per second

b- degrees

c- radians

3. Which factor does the torque on an object NOT depend on?

a- the angle at which the force is applied

b- the object's angular velocity
c- the magnitude of the applied force

4. A net torque applied to an object causes __________.

a- the object to rotate at a constant rate
b- a linear acceleration of the object
c- the moment of inertia of the object to change
d- the angular velocity of the object to change

5. For an extended object, the weight force can be considered to act at which point?

a- At the center of gravity of the object
b- At the center of the object
c- At end of the object closest to the ground
d- At the end of the object farthest away from the ground

6. Moment of inertia is __________.

a- the rotational equivalent of mass
b- the point at which all forces appear to act
c- the time at which inertia occurs

peachgrasshopper627

I would appreciate help with any of the following problems. Thankyou.

22. In an isometric exercise a person places a hand on a scale andpushes vertically downward, keeping the forearm horizontal. This ispossible because the triceps muscle applies an upward forceperpendicular to the arm, as the figure indicates. The forearmweighs 22.1 N and has a center of gravity as indicated. The scaleregisters 113 N. Determine the magnitude of .
Distance between the force applied by the muscle and the elbowjoint 0.025 m. The distance between the elbow joint and the armscenter of gravity is 0.15 m. Distance between the arms center ofgravity and the center of the scale is 0.15 m. I was not able tofind the answer to this problem using the solution posted on thewebsite.

26.A wrecking ball (weight = 4310 N) is supported by a boom, whichmay be assumed to be uniform and has a weight of 2550 N. As thedrawing shows, a support cable runs from the top of the boom to thetractor. The angle between the support cable and the horizontal is32Â°, and the angle between the boom and the horizontal is 48Â°. Find(a) the tension in the support cable and (b) the magnitude of theforce exerted on the lower end of the boom by the hinge at pointP.

56. Two identical wheels are moving on horizontal surfaces. Thecenter of mass of each has the same linear speed. However, onewheel is rolling, while the other is sliding on a frictionlesssurface without rolling. Each wheel then encounters an inclineplane. One continues to roll up the incline, while the othercontinues to slide up. Eventually they come to a momentary halt,because the gravitational force slows them down. Each wheel is adisk of mass 3.64 kg. On the horizontal surfaces the center of massof each wheel moves with a linear speed of 5.26 m/s. (a),(b) Whatis the total kinetic energy of each wheel? (c), (d) Determine themaximum height reached by each wheel as it moves up the incline. Iwas able to solve for the rolling wheel but couldn't find the rightanswers for the sliding wheel.

66. A thin uniform rod is rotating at an angular velocity of 1.89rad/s about an axis that is perpendicular to the rod at its center.As the figure indicates, the rod is hinged at two places,one-quarter of the length from each end. Without the aid ofexternal torques, the rod suddenly assumes a "u" shape, with thearms of the "u" parallel to the rotation axis. What is the angularvelocity of the rotating "u"?

76. A woman who weighs 501 N is leaning against a smooth verticalwall, as the drawing shows. Find (a) the magnitude of the force N(directed perpendicular to the wall) exerted on her shoulders bythe wall and the (b) horizontal and (c) vertical components of theforce exerted on her shoes by the ground.
