LAST NAME: STUDENT NR:
PHYS 1010 6.0: CLASS TEST 2 on Oct. 26, 2012
Time: 50 minutes; Calculators & formulae provided at the end = only aid; ask no questions!
1) [5] A 2.0 kg parcel is launched up a ramp which ends in a horizontal surface with known
initial speed 3.5 m/s. The ramp makes a 30-degree angle with the horizontal and is 2.5 m
long. The coefficient of kinetic friction between parcel and ramp is given as 0.2. Calculate the
velocity vector of the parcel as it arrives at the top of the ramp (it will launch into the air
at this point!). Begin your solution with a complete free-body diagram for the parcel on the
ramp.
1
Unlock document

This preview shows pages 1-2 of the document.
Unlock all 5 pages and 3 million more documents.

Already have an account? Log in
2) [5] A 3.0 kg parcel arrives at the top of a ramp which makes a 45-degree angle with the
horizontal with a speed of 2.4 m/s. It lands some distance daway on the horizontal surface.
Calculate this distance while neglecting air drag. Do not use a (memorized) formula for the
range, but derive your result for dfrom the kinematic equations given in the formula sheet.
Provide a free-body diagram for the parcel while it is airborne.
2
Unlock document

This preview shows pages 1-2 of the document.
Unlock all 5 pages and 3 million more documents.

Already have an account? Log in

Document Summary

Phys 1010 6. 0: class test 2 on oct. 26, 2012. Time: 50 minutes; calculators & formulae provided at the end = only aid; ask no questions: [5] a 2. 0 kg parcel is launched up a ramp which ends in a horizontal surface with known initial speed 3. 5 m/s. The ramp makes a 30-degree angle with the horizontal and is 2. 5 m long. The coe cient of kinetic friction between parcel and ramp is given as 0. 2. Calculate the velocity vector of the parcel as it arrives at the top of the ramp (it will launch into the air at this point!). Begin your solution with a complete free-body diagram for the parcel on the ramp. 1: [5] a 3. 0 kg parcel arrives at the top of a ramp which makes a 45-degree angle with the horizontal with a speed of 2. 4 m/s. It lands some distance d away on the horizontal surface.
