15-213 Final Cheat Sheet

1 Bits, Bytes, Integers

C data type 32-bit 64-bit x86-64

char 1 1 1

short 2 2 2

int 4 4 4

long 4 8 8

float 4 4 4

double 8 8 8

long double - - 10/16

pointer 4 8 8

1.1 Shift Operations

•Logical right shift ﬁlls with 0s, arith-

metic shift ﬁlls with most signiﬁcant

bit.

•Unsigned - logical, signed - arith.,

signed div by 2 rounds to −∞.

•If shift amount n < 0 or n > w,

behavior undeﬁned. Typically, xis

shifted by nmod wwith wword

size.

•K, M, G, T, P = 210,220,230,240 ,250

1.2 Word Sizes

• |TMin|= TMax + 1

•UMax = 2 ·TMax + 1

•#include <limits.h> provides

INT MIN,UINT MAX, etc.

1.3 Signed, Unsigned, Casting

•In casting, the bit pattern is main-

tained and reinterpretted.

•Casting to larger width takes value of

smaller width, using sign extension.

•Casting to smaller with is truncating

bits, similar to modulo.

•Constants are defaulted to signed in-

tegers, unless we put a U at the end,

e.g. int x = 0U;.

•If there is a mix of signed and un-

signed integers, signed values are

implicitly casted to unsigned, in-

cluding comparison operators, e.g. -1

> 0U.

2 Integers

•For unsigned, add/multiply to true

value and then mod by 2w.

•In big endian, intuitive layout, e.g. 01

23 45 67, while in little endian, re-

versed, e.t. 67 45 23 01.

3 Floats

3.1 Representation

•Numeric form: (−1)sM2Ewhere sig-

niﬁcant Mis normally M∈[1.0,2.0).

•Encoded as s | exp | frac.

•Precision options

–Single precision (32 bits): 1|8

| 23

–Double precision (64 bits): 1 |

11 | 52

–Extended precision (80 bits, In-

tel only): 1|15|64

•Normalized values (exp 6= 00 . . . 0,

exp 6= 11 . . . 1)

–Exponent E=Exp−Bias where

Exp is the unsigned value of exp

and Bias = 2k−1−1 where kis

the number of exponent bits.

–Signiﬁcand encoded with im-

plied 1, i.e. M= 1.x1x2. . . x`

where x1x2. . . x`is frac.

•Denormalized values (exp = 00 . . . 0)

–Exponent E= 1 −Bias

–Signiﬁcand encoded with im-

plied 0, i.e. M= 0.x1x2. . . x`

where x1x2. . . x`is frac.

•Denormalized values (exp = 11 . . . 1)

–If frac = 00 . . . 0, ∞.

–If frac = 00 . . . 0, NaN.

•example 0 | 0000 | 000

–0 0000 001 = 1/512

(denorm)

–0 0000 111 = 7/512 (denorm

max)

–0 0001 000 = 8/512 (norm

min)

–0 0111 000 = 1

–0 1110 111 = 15/8*128 =

240 (norm max)

•round to nearest even - if to near-

est 1/4, then 10.00(011) →10.00,

10.00(110) →10.01, 10.11(100) →

11.00, 10.10(100) →10.10

3.2 Operations

•Comparison is essentially the same as

integer comparison, except for NaN,

−0 = 0, etc.

•When doing computation and round-

ing, round to nearest even.

•Multiplication: XOR sign bits, mul-

tiply signiﬁcand, add exponents, nor-

malize signiﬁcand.

•Addition: align exponents, add, ad-

just.

•Casting: double/float →int trun-

cates fractional part like rounding to-

wards 0, int →double is exact,

int →float rounds.

4 Machine Prog: Basics

4.1 Assembly/Machine Code

•Programmer-visible state: PC (pro-

gram counter, address of next in-

struction (%rip)), registers, condi-

tion codes.

•Memory: code and user data, stack

for supporting procedures.

•The lower 4 bytes of %rax are %eax,

divided into %ah | %al.

•%rsp is the stack pointer, which has

a special use.

•Operations

–movq src, dest takes diﬀerent

arguments imm (e.g. $400), reg

(e.g. %rax), mem (8 consec-

utive bytes at address) (e.g.

(%rax)). Cannot move from

mem to mem. movsql sign ex-

tends 32 to 64, movzql doesn’t.

–D(Rb,Ri,S) computes M[R[Rb]

+ S*R[Ri] + D],D∈ {1,2,4}

and S∈ {1,2,4,8}.

–leaq src, dest takes address

mode expression and sets a reg-

ister dest to hold the computa-

tion result.

–addq src, dest does dest =

dest + src.

1
