Document Summary

4: two graduate students measure the strength of an mri"s magnetic field to have the following values: No: suppose we want to linearize by substitution the formula for dependent variable. Kinetic energy (k) with independent variable velocity (v). if the original equation is k= (1/2)mv2, what will our new independent variable (x) be when we map this onto y=mx + b? v2. Post-lab: you perform an experiment in slacking off at work by clocking out earlier each week and seeing how it affects your paycheck. Properly title the graph and label the axes for the plot your collected data. X: time worked (hours: the known area of a table is 1. 50 m2. You measure the length of the table to be. Percent error: measured area known area/known area * 100. Measured area: 1. 25 * 1. 25: momentum is defined as mass times velocity. You find the mass of a car to be.

Related Questions

Theory: Topics that you should be familiar with are: significantfigures, least count and estimated fraction, systematic and randomerrors, accuracy versus precision, percent difference and percenterror. These topics should have been covered in class already (orperhaps in an introduction to the lab manual or in a handout). Itis assumed that the instructor has discussed how to use the massbalance, etc.
Introduction: The goal of section I of this experiment is tomeasure (to the correct least count and estimated fraction) andcalculate (to the correct number of significant figures) thedensity of a metal ball and compare it to a table of accepteddensities (?=7.8x103 kg/m3).
To accomplish this goal keep in mind that: ? = m/V and Vsphere =(4/3) p r3
In the space below create a data table, show your calculations indetail, and compare your measured answer to accepted values givenabove. (Would you calculate a percent error or a percentdifference?)
1
II. Is g (the acceleration due to gravity) a constant? If so, whatis it?
1) SetuptheFree-FallApparatusasdemonstratedbytheinstructor.
2)MeasurethetimeittakesforthemetalballtofallthroughthesuggesteddisplacementsshowninDataTable 1. Be sure to do 4 trials for each fall and take the averageof your time and displacement. For each trial measure thedisplacement and record your results as precisely as possible. Becareful how you measure the displacement!
Data Table 1
Displacement (meters) Time
Trial 1
___.40___ m .281 s
______.40_ m .284 s
___.40____ m .283 s
____.40___ m .285 s
Average Displacement =.40 m Average time .0285 s
Trial 2
____.60___ m .357 s
____.60___ m .358 s
_____.60__ m .347 s
____.60___ m .347 s
Time (seconds)
Average Displacement = .60 Average Time = .352
Trial3
_.80____ m .402 s
_.80____ m .401 s
_.80______ m .402 S
_.80___ m .401 s
Average Displacement = .80 m Average Time =.401 s

Trial4
__ 1.00____ m .454 s
___1.00____ m .453 s
___1.00____ m .463 s
___1.00____ m .453 s
Average Displacement = 1.00 m Average Time =.455 s
3)PlotDisplacement(usetheaveragedisplacement)asafunctionofTime(usetheaveragetime)usingacomputer software that you know the best. (Does Displacement orTime go on the âverticalâ (or y) axis? Make sure that you label theaxes of your graph properly and give the graph a descriptivetitle.), Please include (0,0) point.
4)UsetheCurveFitFunctiontotrytofindthecurvethatistheclosestfitforthegraph.Whichofthefollowing curve types gives the best fit? Try each to findout.
a) linear fit? b) quadratic (power 2)? c) exponential? d) Power?
The curve with the correlation coefficient (R) closest to 1 has theclosest fit. (e.g. 0.997 is better than 0.956)
5)Printthecurvewiththeclosestfit(oneforeachmemberofthelabgroup).Besureyourgraphincludesthe equation for your fit.
6)Canyoudeterminetheexperimentalaccelerationofgravityfromthisgraph?Explainhowandshowyourwork.
7)Ifalinearfunctionisnotthebestfitofyourplotfromstep3),howwouldyouplotdisplacementandtimeso that the resulting plot is linear? Explain. (Ask your instructorfor a hint if you are not sure of what to do, but be sure to thinkabout it for a while before you ask.)
3
8)Printacopyofthegraphforeachlabpartnershowingalinearfittoyourdataandproperlylabeledaxes.
9)Canyoudeterminetheexperimentalaccelerationduetogravityfromthisgraph?Explainandshowyourwork.
10) How do your experimental values of âgâ compare with theaccepted value (g = 9.80 m/s2) for the acceleration of gravity?Give a mathematical comparison using what you learned aboutmeasurements previously. (Show work)
4
Question and further procedures
1. What is the greatest source of error in performing theexperiment? Is this error random or systematic? Explain.
2. At this point you should have calculated g in two different ways(A quadratic graph, and a linear graph). Which technique do youthink is best? Do all two techniques give the same answer? If not,which technique do you think has the most error?
3. How might you modify your procedures to determine whether or notg depends on the mass of the falling object? Do the experiment andcalculate g using your favorite technique.
