- Configuring Static Routes -
Configuring Static Routes
The basic syntax for a static route is as follows:
Router(config)# ip route [destination_network] [subnet_mask] [next-hop]
Consider the following example:
RouterA will have the 172.16.0.0/16 and 172.17.0.0/16 networks in its
routing table as directly-connected routes. To add a static route on RouterA,
pointing to the 172.18.0.0/16 network off of RouterB:
RouterA(config)# ip route 172.18.0.0 255.255.0.0 172.17.1.2
Notice that we point to the IP address on RouterB’s fa0/0 interface as the
next-hop address. Likewise, to add a static route on RouterB, pointing to the
172.16.0.0/16 network off of RouterA:
RouterB(config)# ip route 172.16.0.0 255.255.0.0 172.17.1.1
To remove a static route, simply type no in front of it:
RouterA(config)# no ip route 172.18.0.0 255.255.0.0 172.17.1.2
On point-to-point links, an exit-interface can be specified instead of a next-
hop address. Still using the previous diagram as an example:
RouterA(config)# ip route 172.18.0.0 255.255.0.0 fa0/1
RouterB(config)# ip route 172.16.0.0 255.255.0.0 fa0/0
A static route using an exit-interface has an Administrative Distance of 0, as
opposed to the default AD of 1 for static routes. An exit-interface is only
functional on a point-to-point link, as there is only one possible next-hop
device.
