**preview**shows half of the first page. to view the full**3 pages of the document.**Chapter 5 – Regression

5.1 – Regression Lines

- A regression line is a straight line that describes how a response variable y changes as an explanatory

variable x changes

o Often use regression lines to predict the value of y for a given value of x when we believe the

relationship between y and x is linear

- A straight line relating y to x has an equation of the form

y = a +bx

o In this equation, b is the slope, the amount by which y changes when x increases by one unit

o The number a is the intercept, the value of y when x = 0

- The slope of a regression line is an important numerical description of the relationship between the two

variables

o Although we need the value of the intercept to draw the line, this value is statistically meaningful

only when the explanatory variable can actually take values close to zero

5.2 – The Least-Squares Regression Line

- In most cases, no line will pass exactly through all the points in a scatterplot

o Different people will draw different lines by eye, so we need a way to draw a regression line that

doesn’t depend on our guess of here the line should go

o Because we use the line to predict y from x, the prediction errors we make are errors in y, the

vertical direction in the scatterplot

- A good regression line makes the vertical distances of the points from the line as small as possible

- There are many ways to make the collection of vertical distances as small as possible; The most common

is the least-squares method

- The least-squares regression line of y on x is the line that makes the sum of the squares of the vertical

distance of the data points from the line as small as possible

- We write ŷ in the equation of the regression line to emphasize that the line gives a predicted response ŷ

for any x

o Because of the scatter of points about the line, the predicted response will usually not be exactly

the same as the actually observed response y

5.4 – Facts About Least-Squares Regression

1. The distinction between explanatory and response variables is essential in regression

- Least-squares regression makes the distances of the data points form the line small only in the y direction

2. There is a close connection between correlation and the slope of the least-squares line

- The slope and correlation always have the same sign

- The formula for the slope b says more: along the regression line, a change of one standard deviation in x

corresponds to a change of r standard deviations in y

o When the variables are perfectly correlated, the change in the predicted response ŷ is the same

as the change in x

- As the correlation grows less strong, the prediction ŷ moves less in response to changes in x

3. The least-squares regression line always passed through the point (x-bar, y-bar) on the graph of y against x

4. The correlation r describes the strength of a straight-line relationship

- In the regression setting, this description takes a specific form: the square of the correlation, r2, is the

fraction of the variation in the values of y that is explained by the least-squares regression of y on x
