INTRODUCTION
Light is electromagnetic energy that is emitted in the form of waves.
The visual system begins with the eyes. At the back of the eye is the retina which
contains photoreceptors specialized to covert light energy into neural activity.
The output of the retina is not a reproduction of the intensity of the light falling on it but is
specialized to detect differences in the intensity of light falling on different parts of it.
The first synaptic relay in the pathway that serves visual perception occurs in a cell
group of the dorsal thalamus called the lateral geniculate nucleus (LGN). From the
LGN, visual information ascends to the cerebral cortex where it is interpreted and
remembered.
PROPERTIES OF LIGHT
Light
Electromagnetic radiation:
Wavelength: the distance between successive peaks or troughs
Frequency: the number of waves per second
Amplitude: the difference between wave trough and peak
The energy content of electromagnetic radiation is proportional to its frequency [i.e. high
frequency (short wavelengths) has the highest energy content].
Only a small part of the electromagnetic spectrum is detectable by our visual system.
This visible light consists of wavelengths of 400-700 nm. (see Fig. 9.2)
“Hot” colours (e.g. red or orange) have long wavelength light and less energy than “cool”
colours (e.g. blue or violet).
Optics
In a vacuum, a wave of electromagnetic radiation will travel in a straight line. This is a ray.
Reflection: the bouncing of light rays off a surface. This depends on the angle at which it
strikes the surface. A ray striking a mirror perpendicularly is reflected 180˚ back upon
itself and a ray striking a mirror at 45˚ angle is reflected 90˚.
Absorption: the transfer of light energy to a particle or surface. Black surfaces absorb the
energy of all visible wavelengths. Some absorb light energy only in a limited range of
wavelengths and reflect the remaining wavelengths. For example, a blue pigment
absorbs long wavelengths but reflects a range of short wavelengths centered on 430 nm
that are perceived as blue.
Refraction: the bending of light rays that occur when they travel from one transparent
medium to another. It occurs because the speed of light differs in two media (e.g. light
passes through air more rapidly than through water). The greater the difference between
the speeds of lights in the two media, the greater the angle of refraction. (see Fig. 9.3).
THE STRUCTURE OF THE EYE
Gross Anatomy of the Eye
Pupil: the opening that allows light to enter the eye and reach the retina. It appears dark
due to the light-absorbing pigments in the retina.

Only pages 1-2 are available for preview. Some parts have been intentionally blurred.

Iris: surrounds the pupil and provides the eye’s colour. It contains two muscles: one to
make the pupils smaller when it contracts and the other to make the pupils larger.
Cornea: a glassy transparent external surface of the eye that covers the pupil and iris.
Sclera: the “white of the eye” which is continuous with the cornea. It forms the tough wall
of the eyeball. The eyeball sits in the eye’s orbit. Into the sclera are three pairs of
extraocular muscles lying behind the conjunctiva and move the eyeball in the orbit.
Optic nerve: carries axons from the retina to the base of the brain near the pituitary.
Ophthalamoscopic Appearance of the Eye
Optic disk: a pale circular region that gives rise to the retinal vessels and also where the
optic nerve fibers exit the retina. Sensation of light cannot occur here because there are
NO photoreceptors. Also sensation of light cannot occur where the large blood vessels
exist because the vessels cast shadows on the retina.
Macula: located at the middle of the retina. It is responsible for central vision and lacks
large blood vessels which improve the quality of central vision.
Fovea: a dark spot about 2mm in diameter.
Cross-Sectional Anatomy of the Eye
Aqueous Humor: it is the fluid behind the cornea which nourishes it
Lens: located behind the iris and is suspended by zonule fibers attached to the ciliary
muscles. Changes in the shape of the lens allow the eyes to adjust their focus to
different viewing distances.
o The ciliary muscles are attached to the sclera and form a ring inside the eye. They also
divides the interior of the eye into two compartments containing slightly different fluids:
The aqueous humor which lies between the cornea and lens, and
The more viscous, jellylike vitreous humor which lies between the lens and the
retina and serve to keep the eyeball spherical.
IMAGE FORMATION BY THE EYE
Cornea, rather than the lens, is the site of most of the refractive power of the eyes
Refraction by the Cornea
Light strikes the cornea and passes from the air into the aqueous humor. Then light rays bend
and converge on the back of the eye (see Fig. 9.7)
Focal distance: the distance from the refractive surface to the point where parallel light rays
converge and depends on the curvature of the cornea (i.e. tight the curve, the shorter the focal
distance).
Diopter: reciprocal of the focal distance in meters. The cornea has a refractive power of 42
diopters which means that parallel light rays striking the corneal surface will be focused 0.024 m
(2.4 cm).
Refractive power depends on the slowing of light at the air-cornea interface. If we replace air
with a medium that passes light at about the same speed as the eye, the refractive power will
eliminated. This is why one’s vision is blurry when you open your eyes underwater.
You're Reading a Preview

Unlock to view full version

Only pages 1-2 are available for preview. Some parts have been intentionally blurred.

Accommodation by the Lens
The lens contributes another dozen or so diopters to the formation of a sharp image at a
distance. It is, however, more importantly involved in forming crisp images of objects located
closer than about 9m from the eye.
As objects approach, the light rays originating at a point can no longer be consider to be parallel.
These rays diverge and greater refractive power is required to bring them into focus on the retina.
This focusing power, called accommodation, is provided by changing the shape of the lens (see
Fig. 9.8).
During accommodation, the ciliary muscles contract and swells in. The lens becomes rounder
and thicker, increasing the curvature of the lens surfaces and increases the refractive power.
The ability to accommodate changes with age.
The Pupillary Light Reflex
The pupil continuously adjusts for different ambient light levels.
Pupillary light reflex involves connections between the retina and neurons in the brain
stem that control the muscles that constrict the pupils.
o This reflex is consensual. Shining a light into only one eye cause the constriction of the
pupils of both eyes.
Constriction of the pupil increases the depth of focus.
The Visual Field
It is the points where one can no longer see an object while staring straight ahead (see Fig.
9.9). The left visual field is imaged on the right side of the retina and the right visual field is
imaged on the left side of the retina.
Visual Acuity
It is the ability of the eye to distinguish two nearby points. This depends on several factors
including the spacing of photoreceptors in the retina and the precision of the eye’s refraction.
The distance across the retina can be described in terms of degrees of visual angel (see Fig.
9.10).
MICROSCOPIC ANATOMY OF THE RETINA
The most direct pathway for visual information to exit the eye is: photoreceptors bipolar
cells ganglion cells. In response to light, ganglion cells fire action potentials which
propagate down the optic nerve to the rest of the brain. Retinal process is influenced by two
additional cell types:
Horizontal cells: receives input from the photoreceptors and project neurites laterally to
influence surrounding bipolar cells and photoreceptors.
Amacrine cells: receive inputs from bipolar cells and project laterally to influence
surrounding ganglion cell, bipolar cells and other amacrine cells.
There are two important points to remember:
o Only light-sensitive cells in the retina are the photoreceptors. All other cells are influence
by light only via direct and indirect synaptic interactions with the photoreceptors.
