Chapter 10
Map Accuracy and Uncertainty
Map accuracy Closeness of the map representation to the geographic phenomena.
Basic Characteristics of Maps
Maps are graphical representation of a geographical setting; a collection of symbols used
to represent a portion of the earth.
- All maps are concerned with two primary elements locations and attributes.
- All maps are reductions of reality and therefore require scale conversions.
- All maps are transformations of space involving applications of map
projections and coordinate systems.
- All are also abstractions of reality and therefore require generalization of the
geographic information.
- All maps use signs and symbolism; this is called cartographic symbolization
Maps must maintain their connection toand present a useful representation ofreality.
This has to be balanced against scale, projection, generalization, and symbolism
requirements. Some degree of representational quality has to be sacrificed.
Scale and Accuracy
- The ability to show detail on a map is determined by its scale because that dictates
the amount of space available.
- When features are displayed in smaller spaces, distances. between the symbols
and lengths of features are reduced.
- When features become too small to see, everything else becomes small and
cluttered.
- Visual chaos can result.
- Cartographers have to take decisions carefully in making maps.
- A large scale map of 1:1,000 will show less area with more detail than a smaller-
scale map of 1:250,000
- All maps are abstractions of reality, they require reduction of information content
in order for features to be legible.
Cartographic Abstraction
- Cartographic Abstraction is the process of transforming data that have ben
collected about our environment into a graphical representation of features and
attributes relevant to the purpose of the map.
- To transform geographic data to a map, cartographers rely on selection,
generalization, classification, and symbolism.
Unlock document

This preview shows pages 1-2 of the document.
Unlock all 6 pages and 3 million more documents.

Already have an account? Log in
o Selection: how much information to portray
o Generalization and classification: they eliminate or deemphasize unwanted
or unneeded detail
o Symbolization: how the information will be shown graphically
Cartographic Selection
- Cartographic selection refers to deciding which classes of features to show on the
map. (Based on purpose of map)
o Example: on large-scale topographic map. You will usually find perennial
streams (those that flow a large portion of the time but cease to flow
occasionally or seasonally) and ephemeral streams (those that flow only
during and immediately after periods of rainfall or snowmelt).
o On smaller scale maps, the above will be eliminated.
Cartographic Generalization
- Cartographic generalization refers to reducing the amount of information on a
map through change to the geometric representation of features.
- The degree of generalization is proportional to a features spatial detail, and
inversely proportional to map scale.
- Loss of detail line generalization for features like boundaries, river, and roads.
o This also causes displacement of features as smoothing cuts off natural
irregularities or causes features to overlap.
o Causes Positional error
o Think of Generalization effects not errors
Vector Generalization operations
- Variety of vector generalization methods
- Source scale the scale at which the data originally derived from their sources.
- Common vector generalization methods:
o Simplification selectively reducing the number of points required to
represent an object
o Smoothing Reducing angularity of angles between lines
o Aggregation grouping point locations and representing them as areal
objects
o Amalgamation -- grouping of individual areal features into a larger
element
o Collapse replacing an objects physical deatails with a ymbol
representing the object
o Merging grouping of line features
o Refinement selecting specific portions of an object to represent the
entire object
o Exaggeration to amplify a specific portion of an object
o Enhancement to elevate the message imparted by the object
o Displacement separating object
o
