Chapter 4 : The visual cortex and beyond
Light is refl ected from an object into the eye. This light is focused to form an image of that object on the
retina. Light, in a pattern that illuminates some receptors intensely and some dimly, is absorbed by the
visual pigment molecules that pack the rod and cone outer segments. Chemical reactions in the outer
segments transduce the light into electrical signals. As these electrical signals travel through the retina,
they interact, excite, and inhibit, eventually reaching the ganglion cells, which because of this processing
have center-surround receptive fi elds on the retina. After being processed by the retina these electrical
signals are sent out the back of the eye in fi bers of the optic nerve.
Followng signals form the retina cortex
- One way researchers have approached this problem is by determining how neurons at various
places in the visual system respond to stimuli presented to the retina.
- The visual system Most of the signals from the retina travel out of the eye in the optic nerve to the
lateral geniculate nucleus (LGN) in the thalamus. From here, signals travel to the primary visual
receiving area in the occipital lobe of the cortex. The visual receiving area is also called the striate
cortex because of the white stripes (striate _ striped) that are created within this area of cortex by
nerve fi bers that run through it (Glickstein, 1988). From the striate cortex, signals are transmitted
along two pathways, one to the temporal lobe and the other to the parietal lobe (blue arrows).
Visual signals also reach areas in the frontal lobe of VL 1 the brain.
- superior colliculus, an area involved in controlling eye movements and other visual behaviors that
receives about 10 percent of the fi bers from the optic nerve. This view also shows how signals
from half of each retina cross over to the opposite side of the brain
Processing in the lateral-geniculate nuclei
Receptive field of LGN Neurons
- neurons in the LGN, like neurons in the optic nerve, respond best to small spots of light on the
- But further investigation reveals that a major function of the LGN is apparently not to create new
receptive fi eld properties, but to regulate neural information as it fl ows from the retina to the
Information flow in the LGN
- Thus, the LGN receives information from many sources, including the cortex, and then sends its
output to the cortex.
- Notice that (1) the LGN receives more input back from the cortex than it receives from the retina
and (2) the smallest signal of all is from the LGN to the cortex. For every 10 nerve impulses the
LGN receives from the retina, it sends only 4 to the cortex. This decrease in fi ring that occurs at
the LGN is one reason for the suggestion that one of the purposes of the LGN is to regulate
neural information as it fl ows from the retina to the cortex.
- But the LGN not only regulates information fl owing through it; it also organizes the information
- We will see that the signals arriving at the LGN are sorted and organized based on the eye they
came from, the receptors that generated them, and the type of environmental information that is
represented in them.
Organizing by left and right eyes
- The lateral geniculate nucleus (LGN) is a bilateral structure, which means there is one LGN in the
left hemisphere and one in the right hemisphere
- ipsilateral eye, the eye on the same side of the body as the LGN.
- contralateral eye, the eye on the opposite side of the body from the LGN. Thus, each eye sends
half of its neurons to the LGN that is located in the left hemisphere of the brain and half to the
LGN that is located in the right hemisphere.
Organization as a spatial map
- When the man looks at the cup, points A, B, and C on the cup are imaged on points A, B, and C
of the retina, and each place on the retina corresponds to a specifi c place on the lateral
geniculate nucleus (LGN).
- This correspondence between points on the LGN and points on the retina creates a retinotopic
map on the LGN—a map in which each point on the LGN corresponds to a point on the retina.
- We can determine what this map looks like by recording from neurons in the LGN.
- The correspondence between locations on the retina and locations on the LGN means that
neurons entering the LGN are arranged so that fi bers carrying signals from the same area of the
retina end up in the same area of the LGN, each location on the LGN corresponds to a location
on the retina, and neighboring locations on the LGN correspond to neighboring locations on the
- Thus, the receptive fi elds of neurons that are near each other in the LGN, such as neurons A, B,
and C, in layer 6 (Figure 4.5), are adjacent to each other at A_, B_, and C_ on the retina.
Receptive fields of neurons in the striate cortex
- In fact, more than 80 percent of the cortex responds to visual stimuli (Felleman & Van Essen,
1991). The idea that most of the cortex responds when the retina is stimulated is the result of
research that began in the late 1950s.
- found cells in the striate cortex with receptive fi elds that, like center-surround receptive fi elds of
neurons in the retina and LGN, have excitatory and inhibitory areas. However, these areas are
arranged side by side rather than in the center-surround confi guration (Figure 4.6a). Cells with
these side- by- VL 2 side receptive fi elds are called simple cortical cells.
- We can tell from the layout of the excitatory and inhibitory areas of the simple cell shown in
Figure 4.6a that a cell with this receptive fi eld would respond best to vertical bars
- The relationship between orientation and fi ring is indicated by a neuron’s orientation tuning
curve, which is determined by measuring the responses of a simple cortical cell to bars with
- impulses per second to a vertically oriented bar and that the cell’s response decreases as the bar
is tilted away from the vertical, and begins stimulating inhibitory areas of the neuron’s receptive fi
- there are neurons that respond to all of VL 3 the orientations that exist in the environment
- they found that many of the cells they encountered in the cortex refused to respond to small spots
- Wiesel changed their stimuli from small spots to moving lines and were then able to fi nd cells
that responded to oriented moving bars. As with simple cells, a particular VL 4 neuron had a
- Complex cells, like simple cells, respond best to bars of a particular orientation.
- However, unlike simple cells, which respond to small spots of light or to stationary stimuli, most
complex cells respond only when a correctly oriented bar of light moves across the entire
receptive fi eld.
- Further, many complex cells respond best to a particular direction of movement
- Another type of cell, called end-stopped cells, fi re to moving lines of a specifi c length or to
moving corners or angles
- some neurons in the cortex respond only to oriented lines was an extremely important discovery
because it indicates that neurons in the cortex do not simply respond to “light”; they respond to
some patterns of light and not to others.
- Hubel and Wiesel’s discovery that neurons respond selectively to stationary and moving lines
was an important step toward determining how neurons respond to more complex objects.
- Because simple, complex, and end-stopped cells fi re in response to specifi c features of the
stimulus, such as orientation or direction of movement, they are sometimes called feature
- Retinal ganglion cells respond best to spots of light, whereas cortical end-stopped cells respond
best to bars of a certain length that are moving in a particular direction.
De feature detectors play a role in perception
Selective adaptation and feature detectors
- The idea behind selective adaptation is that if the neurons fi re for long enough, they become
fatigued, or adapt. This adaptation causes two physiological effects: (1) the neuron’s fi ring rate
decreases, and (2) the neuron fi res less when that stimulus is immediately presented again.
According to this idea, presenting a vertical line causes neurons that respond to vertical lines to
respond, but as these presentations continue, these neurons eventually begin to fi re less to
vertical lines. Adaptation is selective because only the neurons that respond to verticals or near-
verticals adapt, and other neurons do not.
- if these adapted neurons have anything to do with perception, then adaptation of neurons that
respond to verticals should result in the perceptual effect of becoming selectively less sensitive to
verticals, but not to other orientations.
Grating stimuli and the contrast threshold
- Grating stimuli are alternating bars.
- A grating’s contrast threshold is the difference in intensity at which the bars can just barely be
- The important result of this experiment is that our psychophysical curve shows that adaptation
selectively affects only some orientations, just as neurons selectively respond to only some
- The psychophysical curve is slightly wider because the adapting grating affects not only neurons
that respond best to verticals, but also more weakly affects some neurons that respond to nearby
- The near-match between the orientation selectivity of neurons and the perceptual effect of
selective adaptation supports the idea that orientation detectors play a role in perception.
Selective rearing and feature detectors
- The idea behind selective rearing is that if an animal is reared in an environment that contains
only certain types of stimuli, then neurons that respond to these stimuli will become more
- his follows from a phenomenon called neural plasticity or experience-dependent plasticity—the
idea that the response properties of neurons can be shaped by perceptual experience.
- According to this idea, rearing an animal in an environment that contains only vertical lines
should result in the animal’s visual system having neurons that respond predominantly to
- This result may seem to contradict the results of the selective adaptation experiment just
described, in which exposure to verticals decreases the response to verticals. However, the
selective rearing effect occurs over a longer timescale and is strongest in young animals, whose
visual systems are still developing.
- Thus, when a kitten is exposed only to verticals, some adaptation to vertical orientations may take
place (causing the response to verticals to decrease), but as the animal develops, vertically
responding neurons become the only neurons that respond at all.Thus,
Maps and columns in the striate cortex
Maps in the striate cortex
- Thus, nearby points on the cortex receive signals from nearby locations in the retina
- Retinotopic mapping indicates that information about objects near each other in the environment
is processed by neurons near each other in the cortex. This makes sense in terms of effi ciency
Columns in the striate cortex
- the cortex is organized into location columns that are perpendicular to the surface of the cortex so
that all of the neurons within a location column have their receptive fi elds at the same location on
- the cortex is organized into orientation columns, with each column containing cells that respond
best to a particular orientation
ocular dominance columns
- most neurons respond better to one eye than to the
