CHAPTER 4 | THE ONE TO MANY RELATIONSHIP
The One-to-Many Relationship
1:m (one-to-many): relationship b/w 2 entities is depicted by a line connecting the 2 with
a crow's foot at the many end of the relationship
Update anomalies: problems when we want to insert, delete, or update data
1. Insert anomalies
2. Delete anomalies
3. Update anomalies
Foreign key: used to show link to other table
To distinguish b/w columns w/ identical names, they must by qualified by prefixing the
table name
Referential integrity constraint: maintains the accuracy of a database
o Its application means that every foreign key in a table has an identical primary key in
that same table or another table
o Every foreign key must have a matching primary key (referential integrity rule), and
every primary key must be non-null (entity integrity rule)
Querying a 2-table database:
o Join: creates a new table from 2 existing tables by matching on a column common to
both tables
The matching condition can be =, <>, <=, <, >= and >
This generalized version is called a theta join
When people refer to a join, they mean an equijoin, when the matching
condition is equality
Control break reporting
o Purpose of a join is to collect the necessary data for a report
o Control break report: recognizes that the values in a particular column or columns
hardly change
o The GROUP BY clause is a basic form of control break reporting. It permits grouping
of rows that have the same value for a specified column(s), and it produces one row
for each different value of the grouping column(s)
Regular expression has 3 elements:
1. ^ indicates start searching at the beginning of the string
2. (.){2} specifies that anything is acceptable for the next 2 characters
3. t indicates what the next character, the 3rd, must be
Subqueries
o Subqueries aka inner query
o Outer query: applied to the SQL preceding the inner query
o Correlated subquery: the subquery can't be evaluated independently of the outer
query
Depends on the outer query for the values it needs to resolve the inner query
