0

50

100

150

200

250

300

350

400

Thousands

500 1000 1500 2000 2500 3000 3500 4000

Size (square feet)

House Prices Vrs Size

1983-86 & 1987-88 Figure 2.1

Price

Major

Axis

Chapter 2

Bivariate Distributions

2.1 Descriptive Statistics for Bivariate Distributions: Covariance and Correlation

Chapter 1 focuses on the distribution of single random variables, such as the wage received by an

individual worker. Empirical studies in economics typically seek to understand the relationship between

two or more random variables. For example, how does the level of education affect the wage a worker

can expect to earn? This chapter considers bivariate distributions; the statistical relationship between a

pair of random variables. For example, if X and Y are both normally distributed random variables, their

joint distribution is known as the bivariate normal distribution. Before exploring the properties of a

theoretical distribution such as the bivariate normal, we will consider how descriptive statistics can be

used to capture some essential features of the relationship between a pair of variables.

Figure 2.1 is a scatter diagram of house prices and house sizes. Each point in the diagram

corresponds to the price and size of a particular house. The sample consists of 2181 observations on

house sales gathered over a 6 year period: 1983-88 (but the sample has no data for 1986.) Price refers to

the price for which the house sold and size is the total floor space of the house measured in square feet.

The scatter plot reveals a positive relationship between size and price - the scatter of points stretches up

from the lower left towards the top right. It confirms what we would expect: larger houses tend to sell

for higher prices. An interesting question that these data can answer is: by how much does the market

price increase when size increases? Indeed the central goal of this chapter is to consider how we might

frame and answer the question of the quantitative relationship between two variables such as the size and

price of houses. Is the relationship linear or nonlinear? If it is linear, then what line “best” represents the

Econometrics Text by D M Prescott © Chapter 2, 2

1 The scatter seems to be split into two concentrations, one above the other. The 1987-88 data

presumably lie above the 1983-85 data, being separated by a gap created by the unrecorded 1986 data.

Intercept ¯

Yslope×¯

X$(95510 114.74×1313.5) $55201

size-price relationship?

A natural choice for the line that captures the linear relationship between size and price is known

as the major axis which is drawn in Figure 2.1. The key properties of the major axis are listed in Table

2.1. In particular, the slope of the major axis is the standard deviation of the Y-axis variable (price)

divided by the standard deviation of the X-axis variable (size.)

Table 2.1

Properties of the Major Axis

1. The slope is the ratio of standard deviations: SD(Y)/SD(X); Y is Price (P) and X is Size (S)

2. Passes through the sample mean point: (¯

X,¯

Y)

3. Bisects the scatter plot symmetrically

The information in Table 2.2 lists univariate sample statistics for price and size and these can be

used to calculate the slope of the major axis which is ($43113)/(375.7 sq ft) = $114.74 per square foot.

To plot the major axis in Figure 2.1 it is necessary to find its linear equation (slope and intercept). The

intercept is chosen so that the major axis passes through the sample mean. The following formula

guarantees this result:

The equation of the major axis in Figure 2.1 is therefore P = -55201 + 114.7S

Although Figure 2.1 shows a positive relationship between size and price, the points are clearly

dispersed around the major axis. For any particular size that is fixed on the X-axis, house prices span a

wide range because other variables affect the market price of houses. The age of a house, its location and

a host of other factors all play a part in determining market value. An important variable is the date of

the sale. These data were collected during the 1980s when property prices in Canada were rising and that

explains some of the vertical spread in the plot - for any given size, prices in 1988 will generally be much

higher than in 1983.1

Econometrics Text by D M Prescott © Chapter 2, 3

0

50

100

150

200

250

300

Thousands

500 1000 1500 2000 2500 3000 3500 4000

Size (square feet)

House Prices Vrs Size

1983-86 & 1987-88 Figure 2.2

Price

Mean Price =

$99,500

Mean Size =

1,313 sq ft

TABLE 2.2

Sample Statistics: Price & Size

Number of Observations: 2181

Mean Std Dev Minimum Maximum

P 95509.95598 43113.87056 22000.00 300000.00

S 1313.49198 375.74706 700.00 3850.00

Variance Skewness Median

P 1.85881D+09 0.98675 86000.00

S 141185.85 1.44909 1200.00

Figure 2.1 suggests there is a positive relationship between house size and its price. The

covariance and correlation coefficient between two variables are statistics that capture aspects of the

linear relationship between two variables. Figure 2.2 shows the size-price scatter plot and four

quadrants defined by the means of size and price.

The basic ingredient in the covariance between two variables Y and X is the cross-product of the

deviations from the means: .

(Xi¯

X)(Yi¯

Y), i1, 2, ,..., n
