Decision Structures
Rules that allow for a program to have multiple laths of execution
Common to all programming languages
Rules follow the way we think about different scenarios
If a student is a freshman, schedule for new student orientation
If a s student is a freshman, schedule for new student orientation. Else if
a student is a senior, welcome them and remind them of graduation
requirements paperwork. Else send a welcome back message
“If” Decision Structure
Conditional execution based on a boolean expression
A boolean expression is an expression that evaluates to true or false
Result of method calls
Result of relational operators
If (expression)
statement
If (expression)
{
statement 1
statement 2
}
If the expression’s conditions are not met, the program will jump to the end of the
block
Can have many else ifs, but only one else
You can nest if statements within each other
Double ampersand means true, otherwise one is false ?
Relational Operators
X and Y are primitive types (int, byte, double..)
For objects, use equals or compareTo
<, >, <=, >=, ==
Logical Operators
Join two or more relational operations into a single operation (see truth tables in
powerpoint)
Logical, relational and arithmetic operation have a complex precedence structure
&&: The only time something is true, is when both conditions are true, otherwise the
result is false
&& = AND
|| = OR (see example below, opposite of ampersand)
! = NOT
When you have a complex expression, it will do the arithmetic operations first, then relational
operators, THEN logical operators.
3+5 < 7 || 8-2 >= 5
8 < 7 || 6 >= 5
false || true
true
