Solar Radiation//Christopherson, Chp.2
Goals to learn this lecture:
-What is electromagnetic radiation?
-What are the patterns of receipt of solar radiation on Earth?
-What are seasons and why do we have them?
Why it’s important: solar radiation drives physical systems and the biosphere
abbreviations used in document: ‘sorad’ = solar radiation; ‘bill.’ = ‘billion’; ‘amnt’ =
‘amount. Others should be self-explanatory I hope.
Earth-Sun relationships are critical to how Earth systems behave
-Revolution and Rotation = 2 very distinct characteristic of Earth
>Revolution: Earth orbits annually around sun in an ellipse (1 complete revolution/year)
>Rotation: Earth rotates eastwards daily on own axis, which gives day and night
aphelion and perihelion: related to certain distances of Earth from Sun at diff. times
aphelion. = July 4th/Summer: Earth at its farthest from Sun at this point in revolution
perihelion. = January 3rd/Winter: Earth at its closest to Sun at this point in revolution
>Aphelion and perihelion raise questions against misconceptions about proximity to
Sun equitable with seasonality, since further we are, it’s summer, whereas closer we
are, it’s winter.
The Sun
-typical of one of several 100 bill. stars in Milky Way Galaxy
-6000K @ surface
-Enormous mass @ high temp. & pressure nuclear fusion
-Sun emits charged particles which give phenomena such as solar wind, short-wave
radiation
>emits , at surface, high energy radiation travelling at speed of light
Radiation
-energy transmitted as waves of electric and magnetic oscillations
-ELECTROMAGNETIC RADIATION is emitted by all matter with a temp. above absolute 0/
0K
-radiation intensity emitted depends on the temp. of the object: Stefan-Boltzmann law
Q proportional to T^4
-Wavelength of radiation inversely related to surface temp (hotter = shorter
wavelengths)
>wavelength is distance ‘twixt two adjacent peaks.
Why human beings dont glow...
-comfy human skin temp ~ 33Cs
-Avg. Human surface area ~ 1.8m^2
-895 watts emitted (1 watt = 1 joule/s)PWR = energy emitted per unit time. Watt= unit
of PWR.
-This is similar to 9 household light bulbs
-Radiation is in the thermal infrared part of the spectrum (heat) not visible light; which
is why human beings don’t glow
Solar Radiation//Christopherson, Chp.2
Some Def’ns
Ozone layer: contains ozone (O3) which absorbs much sorad (UV and X-ray). Else we’d
die rightquick.
Thermopause: outer boundary of Earth’s energy system
Solar constant: Avg. Insolation received at thermopause when Earth is at its avg.
Distance from Sun
Watt: standard unit of PWR [energy (Joules) per unit time (seconds)]
Absorption of diff. wavelengths by gases in the atmosphere
How much insolation does Earth intercept?
-Incoming short wave radiation at the top of the atmosphere = 1372W/m^2 (solar
constant)
-Sub-solar point: where sun is directly overhead; most intense, maximum receipt of
sorad.
>varies with the seasons
>more diffuse as you move away
Avrg. Daily latitudinal energy imbalance @ top of atmosphere is spatial variation
Net R : total amnt of radiation @ given point in atmosphere in watts/m^2
- isolines connect points of equal sorad receipt
-Earth’s “heat engines” distribute energy (wind, ocean currents and weather)
>Earth’s many irregularities make ‘imbalance’ in terms of equator isn’t necessarily
hottest at isolines
Seasonal changes in insolation are called temporal variation
-Changes in Sun’s position above horizon and in day length
-Declination = latitude of sub-solar point
>where Sun is in terms of sub-solar pt. Determines seasons
Declination of Sun: Where Sun is above horizon
Revolution
-Revolution around Sun: length of seasons
-Difference between aphelion and perihelion not significant
-Eccentricity (epsilon): degree of departure from perfectly circular orbit
>varies from 0-1
>Earth’s epsilon = 0.0167 (thus nearly circular)
>Eccentricity aren’t too significant for determining Earth’s seasons
Rotation and orbital position
-Rotation around Earth’s axis: day length
-Equator: day length = 12 hrs year round
Tilt: Earth’s axial tilt is major factor in explaining seasons
>Earth axis is at 23.5 degree tilt from plane of ecliptic
>axis always points to Polaris (North Star), regardless of time of year = “axial
Solar Radiation//Christopherson, Chp.2
parallelism”
Annual march of the seasons
Equinoxes: circle of illumination passes through both poles, Day length = 12 hrs.
everywhere
