MGMT 1050 Lecture 1 Notes – Memory in the Data
Introduction
• Once this has occurred, the data is in memory, ready for the program to use.
• This technique of I/O–memory data transfer is known as direct memory access, or more
commonly, simply as DMA.
• In Little Man terms, direct memory access could be viewed as providing data for the
Little Man by loading data directly into the mailboxes through a rear door, bypassing the
Little Man I/O instruction procedures.
• To reemphasize the fact that this operation only takes place under program control, we
would have to provide a means for the Little Man to initiate such a transfer and a means
to notify the Little Man when the data transfer is complete.
• For direct memory access to take place, three primary conditions must be met
• There must be a method to connect together the I/O interface and memory.
• In some systems both are already connected to the same bus, so this requirement is
easily met.
• In other cases, the design must contain provisions for interconnecting the two.
• The issue of system configuration is discussed
• The I/O module associated with the particular device must be capable of reading and
writing to memory.
• It does so y siulatig the CPU’s iterfae with eory.
• Specifically, the I/O module must be able to load a memory address register and to read
and write to a memory data register, whether its own or one outside the I/O module.
• There must be a means to avoid conflict between the CPU and the I/O module.
• It is not possible for the CPU and a module that is controlling disk I/O to load different
addresses into the MAR at the same instant.
• For example, nor is it possible for two different I/O modules to transfer data between
I/O and memory on the same bus at the same instant.
find more resources at oneclass.com
find more resources at oneclass.com
• This requirement simply means that memory can only be used by one device at a time,
although
• As we mentioned, some systems interleave memory in such a way that the CPU and I/O
modules can access different parts of memory simultaneously.
• Memory data transfer is known as direct memory access, or more commonly, simply as
DMA.
• In Little Man terms, direct memory access could be viewed as providing data for the
Little Man by loading data directly into the mailboxes through a rear door, bypassing the
Little Man I/O instruction procedures.
• To reemphasize the fact that this operation only takes place under program control, we
would have to provide a means for the Little Man to initiate such a transfer and a means
to notify the Little Man when the data transfer is complete.
• For direct memory access to take place, three primary conditions must be met
• There must be a method to connect together the I/O interface and memory.
• In some systems both are already connected to the same bus, so this requirement is
easily met.
• In other cases, the design must contain provisions for interconnecting the two.
• The issue of system configuration is discussed
• The I/O module associated with the particular device must be capable of reading and
writing to memory.
• It does so y siulatig the CPU’s iterfae with eory.
• Specifically, the I/O module must be able to load a memory address register and to read
and write to a memory data register, whether its own or one outside the I/O module.
• There must be a means to avoid conflict between the CPU and the I/O module.
