Batteries and Fuel Cells, Electrolysis
• Primary Cells (or batteries).
-Cell reaction is not reversible.
• Secondary Cells.
-Cell reaction can be reversed by passing electricity through the cell (charging).
• Flow Batteries and Fuel Cells.
-Materials pass through the battery which converts chemical energy to electric energy.
The Leclanché (dry) cell:
The Leclanché dry cell is the most common type of voltaic cell, invented by Georges Leclanché in
the 1860’s.
-It is called a dry cell because there is no free liquid present.
-It is cheap to produce, but as a primary cell, cannot be recharged.
-Oxidation: Zn(s) → Zn2+(aq) + 2 e
-Reduction: 2 MnO2 (s) + H2O(l) + 2 e - → Mn2O3 (s) + 2 OH- (aq)
-Acid-base reaction: NH4 + (aq) + OH- (aq) → NH3 (g) + H2O(l)
-Precipitation reaction: NH3 (g) + Zn2+(aq) + 2 Cl- (aq) → [Zn(NH3 )2 ]Cl2 (s)
- The NH3 (g) must be removed by complexing it to Zn2+ or it will adhere to the cathode, disrupting the
current
The Alkaline Cell
-Reduction: 2 MnO2 (s) + H2O(l) + 2 e - → Mn2O3 (s) + 2 OH- (aq)
-Oxidation reaction can be thought of taking place in two steps:
Zn(s) → Zn2+(aq) + 2 e –
Zn2+(aq) + 2 OH- (aq) → Zn(OH)2 (s)
---------------------------------------------------
Zn(s) + 2 OH- (aq) → Zn(OH)2 (s) + 2 e –
Eo cell = Eo (cathode) – Eo (anode)
= Eo (MnO2 /Mn2O3 ) – Eo (Zn(OH)2 /Zn)
= +0.118 V – (-1.246 V)
= +1.364 V
The Silver-Zinc Cell: A Button Battery
Zn(s), ZnO(s) | KOH(sat’d) | Ag2O(s), Ag(s)
Zn(s) + Ag2O(s) → ZnO(s) + 2 Ag(s) Ecell = 1.8 V
- Because no species in the overall reaction are in solution, there is very little electrolyte and the
batteries can be very small
The Nickel-Cadmium Cell: A Rechargeable Battery
2 NiO(OH)(s) + 2 H2O(l) + 2 e- → 2 Ni(OH)2 (s) + 2 OH- (aq)
Cd(s) + 2 OH- (aq) → Cd(OH)2 (s) + 2 e
Cd(s) + 2 NiO(OH)(s) + 2 H2O(l) → 2 Ni(OH)2 (s) + Cd(OH)2 (s)
- charging mode: Cd(s) is the cathode, NiO(OH)(s) is the anode
- decharging mode: NiO(OH)(s) is the cathode, Cd(s) is the anode
- Because they are going back and forth between anode and cathode, it is better to call the Cd(s)
electrode the negative electrode and the NiO(OH)(s) electrode the positive electrode
