Lecture 6: Radiation and Human Health
Radiation and Human Health
•Radiation is everywhere, all around us. We cannot escape radiation. But the
question is what type and how much radiation is there.
•Even if we are walking outside in the woods, we are still exposed to some
radiation, because of Background Radiation: Something that is produced and emitted from
outer space. Natural radioactivity in the earth and by cosmic rays from outer space. This type
of radiation cannot be controlled. We are always exposed to it. It has existed for hundreds of
thousands of years.
•Something that we can control is man made radiation (Electronic devices,
appliances, etc.). (Note: Nowadays, engineers have found technologies to protect us from
most of this radiation). Examples of some man-made devices that emit different types of
- X-ray machines (different kind of equipment used in labs for analysis, for example, CCA
can also be detected using X-ray)
- X-ray Diagnostic (X-ray used for diagnostic of different body parts)
- Television sets
- Microwave ovens
Ionizing radiation exposure to the public
•Natural radiation sources consists of 82% of total measurable radiation
•Man-made radiation is just 18%. Medical x-rays, nuclear medicine can treat some
illnesses and some other types of radiation. What is surprising is that Radon (gas in indoor
air) makes up 55% of total radiation.
Radiation and Human Health
•We have two big groups of radiation:
1) Ionized Radiation (Cosmic, Gamma, X-rays): This is radiation that has so much energy
that can change atoms on some other chemicals. They can push electrons out of their atoms
and produce ionized form of that element. They are very strong as they have so much energy.
(Note: On electric spectrum, elements that are very high in energy have short wavelength,
elements with low energy (non-ionized) have long wavelength.)
2) Non-Ionized Radiation (Radio waves, TV waves, Microwaves): This type does not have
enough energy (low in energy) and they cannot remove electrons from atoms.
Ionized Radiation- How does ionized radiation cause health effects
•Affect of this radiation is obvious. All scientists agree that this radiation is really
harmful. How does it affect human health? First, the radioactive material (like Uranium),
decays naturally and spontaneously, and produces ionizing radiation. This ion radiation, strips
away electrons from atoms (create two charged ions)
•It can also break some chemical bonds. This is important for human body as it
consists of water and chemicals. Examples: alpha, beta particles, gamma and x-rays. These
examples differ based on the amounts of energy they have.
Health effects from exposure to radionuclides
•There are 2 different kinds of health effects.
•1) Stochastic effect (chronic) – Humans exposed to long term, lower level of radiation
Only pages 1-2 are available for preview. Some parts have been intentionally blurred.
•This is most problematic because it is very hard to detect and to know what will
happen to our health after long time exposure to lower level of radiation.
•If the amount of radiation increases, the severity of this affect will not change
and will stay the same and the type of illnesses will be the same (but the risk to get that
illness will increase – i.e. Risk of getting cancer will be higher).
•2 effects associated with this Stochastic health effects:
Cancer is uncontrolled growth of cells (any kinds of cells as there are many kinds of cancers).
Damage at the cellular or molecular levels
Changes in DNA (changes to genetic material). Two problems can happen because of this.
-Teratogenic changes are birth defects (most sensitive in 8-15 week of pregnancy) such as
smaller head or brain size, poorly formed eyes, mental retardation.
-Genetic mutations are changes that can be transferred from the parent to the child.
Teratogenic changes cannot be transferred to the child, but the offspring is affected anyways,
which we see when child is born.
•2) Non-Stochastic effect (acute) – Humans exposed to short term, high levels of
•These effects are also very visible and obvious
•If amount of radiation increases, will get more severe. We know this based on cases of
many different nuclear accidents everywhere (Chernobyl, Hiroshima Nagasaki, workers that
are exposed to very high level of radiation etc.)
•2 effects associated with Non-Stochastic health effects
causes cancerous health effects, but disputed amongst many researchers.
causes radiation sickness (nausea, weakness, hair loss, skin burn or diminishing organ
function, premature aging, death)
Nuclear power plant accidents
•Three Mile Island, Pennsylvania, 1979: Researchers did not find much adverse effects
after this accident because the radiation level was so low that it was not high enough to cause
long term health effects.
•Chernobyl, former Soviet Union, 1986: Here, the radiation levels were so high that
adverse health effects are even seen today. Many kids born with different abnormalities,
increase in number of cancer cases, changes in vegetation and plants.
•Chernobyl accident had 10-20 times higher dose of exposure than Three Mile Island’s
What parts of our body are most sensitive to radiation?
•Highly sensitive parts: Lungs, breast, stomach, colon.
•Moderate Sensitive parts: brain, lymph tissue, liver, ovaries, intestines, pancreas, marrow,
•Low sensitive parts: Skin, gall bladder, kidneys, spleen, bone. These parts are based on
acute, whole-body exposure
Is any amount of radiation safe?
•Some scientists believe yes, and even some lower level of radiation can be beneficial.
•How do we know that radiation causes cancer? Before humans had much information
about radiation, or had high technology, they still saw the problems associated with it.
•In 1910, it was first observed that radiation causes skin cancer
•Then they found more proof that this is true by studying Japanese atomic bomb blast
survivors, also uranium miners,
